#include <Messages.hpp>

Inheritance diagram for WsfL16::Messages::InitialBase:

[legend]

Collaboration diagram for WsfL16::Messages::InitialBase:

[legend]

Public Member Functions
virtual InitialBase *	Clone () const =0
	~InitialBase () override=default
	InitialBase (const InitialBase &aSrc)
const InitialBase &	operator= (const InitialBase &aRhs)=delete
WordType	GetWordType () const override
	Returns the base type of the word.
size_t	GetMessageLength () const
	Returns the number of extra words in the message.
virtual void	GetLabel (int &aLabel, int &aSubLabel) const =0
bool	IsLabelEqual (int aLabel, int aSublabel) const
int	GetLabel () const
int	GetSubLabel () const
Base *	GetSubWord (int index) const
	Returns the sub-word with the given index number.
ContinuationBase *	GetContinuation (int aIndex)
const ContinuationBase *	GetContinuation (int aIndex) const
size_t	GetContinuationCount () const
ContinuationBase *	FindContinuation (int aContinuation) const
size_t	GetExtensionCount () const
ExtensionBase *	GetExtension (int aIndex) const
ContinuationBase *	AddContinuationWord (int aWordNumber)
ExtensionBase *	AddExtensionWord (int aWordNumber)
void	InsertContinuationWord (std::unique_ptr< ContinuationBase >)
	Inserts a new Continuation word into this word.
void	InsertExtensionWord (std::unique_ptr< ExtensionBase >)
	Inserts a new Extension word into this word.
const Header &	GetHeader () const
Header &	GetHeader ()
void	WriteMessage (MessageBitOutput &aMW, bool aWriteHeader=true) const
virtual std::unique_ptr< ContinuationBase >	CreateContinuationWord (int label)=0
	Adds a Continuation word with the given label to this message.
virtual std::unique_ptr< ExtensionBase >	CreateExtensionWord (int aExtensionBaseNumber)=0
	Adds an Extension word with the given ExtensionBase number to this message.
std::string	GetClassName () const override
	Returns the human-readable class name for the Initial word.
void	PrintMessage (ut::log::MessageStream &aStream) const
Public Member Functions inherited from WsfL16::Messages::Base
	Base (char *aData)
	Base ()
virtual	~Base ()
virtual int	GetUID () const =0
	Returns the unique identifier of a message word type.
virtual void	TransferI (MessageBitInput &aMR)=0
	Reads the message from a MessageBitInput.
virtual void	TransferO (MessageBitOutput &aMW)=0
	Reads the message from a MessageBitOutput.
virtual void	CreateAccessor (MessageAccessorFiller &aMP)=0
	Used once to provide generic access to messages and fields.
virtual const char *	GetFieldName (int i)=0
	Returns the name of the field with a given index.
void	PrintWord (ut::log::MessageStream &aStream) const

Protected Member Functions
	InitialBase ()=default
bool	Initialize (const char *aData)
	Initialize the message by reading from the data buffer.

Protected Attributes
std::vector< std::unique_ptr< ContinuationBase > >	mContinuationWords
std::vector< std::unique_ptr< ExtensionBase > >	mExtensionWords
Header	mHeader

Friends
class	Factory

Additional Inherited Members
Public Types inherited from WsfL16::Messages::Base
enum	WordType { cINITIAL , cCONTINUATION , cEXTENSION , cUNDEFINED }

Constructor & Destructor Documentation

◆ ~InitialBase()

WsfL16::Messages::InitialBase::~InitialBase ( )

overridedefault

References InitialBase().

◆ InitialBase() [1/2]

WsfL16::Messages::InitialBase::InitialBase ( const InitialBase & aSrc )

References for(), InitialBase(), mContinuationWords, mExtensionWords, and mHeader.

Referenced by Clone(), InitialBase(), operator=(), WriteMessage(), and ~InitialBase().

◆ InitialBase() [2/2]

WsfL16::Messages::InitialBase::InitialBase ( )

protecteddefault

Member Function Documentation

◆ AddContinuationWord()

ContinuationBase * WsfL16::Messages::InitialBase::AddContinuationWord ( int aWordNumber )

References CreateContinuationWord(), FindContinuation(), and mContinuationWords.

Referenced by WsfL16::Messages::Factory::CreateContinuationWord(), WsfL16::Messages::Factory::CreateFullMessage(), and WsfL16::Messages::Factory::ReadMessage().

◆ AddExtensionWord()

ExtensionBase * WsfL16::Messages::InitialBase::AddExtensionWord ( int aWordNumber )

References CreateExtensionWord(), and InsertExtensionWord().

Referenced by WsfL16::Messages::Factory::CreateExtensionWord(), WsfL16::Messages::Factory::CreateFullMessage(), and WsfL16::Messages::Factory::ReadMessage().

◆ Clone()

virtual InitialBase * WsfL16::Messages::InitialBase::Clone ( ) const

pure virtual

References InitialBase().

◆ CreateContinuationWord()

virtual std::unique_ptr< ContinuationBase > WsfL16::Messages::InitialBase::CreateContinuationWord ( int label )

pure virtual

Adds a Continuation word with the given label to this message.

Referenced by AddContinuationWord().

◆ CreateExtensionWord()

virtual std::unique_ptr< ExtensionBase > WsfL16::Messages::InitialBase::CreateExtensionWord ( int aExtensionBaseNumber )

pure virtual

Adds an Extension word with the given ExtensionBase number to this message.

References GetClassName(), and PrintMessage().

Referenced by AddExtensionWord(), and InsertExtensionWord().

◆ FindContinuation()

ContinuationBase * WsfL16::Messages::InitialBase::FindContinuation ( int aContinuation ) const

References mContinuationWords.

Referenced by AddContinuationWord().

◆ GetClassName()

std::string WsfL16::Messages::InitialBase::GetClassName ( ) const

overridevirtual

Returns the human-readable class name for the Initial word.

Implements WsfL16::Messages::Base.

References GetLabel().

Referenced by CreateExtensionWord().

◆ GetContinuation() [1/2]

ContinuationBase * WsfL16::Messages::InitialBase::GetContinuation ( int aIndex )

inline

References mContinuationWords.

◆ GetContinuation() [2/2]

const ContinuationBase * WsfL16::Messages::InitialBase::GetContinuation ( int aIndex ) const

inline

References mContinuationWords.

◆ GetContinuationCount()

size_t WsfL16::Messages::InitialBase::GetContinuationCount ( ) const

inline

References mContinuationWords.

◆ GetExtension()

ExtensionBase * WsfL16::Messages::InitialBase::GetExtension ( int aIndex ) const

inline

References mExtensionWords.

◆ GetExtensionCount()

size_t WsfL16::Messages::InitialBase::GetExtensionCount ( ) const

inline

References mExtensionWords.

◆ GetHeader() [1/2]

Header & WsfL16::Messages::InitialBase::GetHeader ( )

inline

References mHeader.

◆ GetHeader() [2/2]

const Header & WsfL16::Messages::InitialBase::GetHeader ( ) const

inline

References mHeader.

Referenced by WsfL16::Messages::Factory::ReadMessage(), and WsfL16::Interface::SendJMessage().

◆ GetLabel() [1/2]

int WsfL16::Messages::InitialBase::GetLabel ( ) const

inline

References GetLabel().

◆ GetLabel() [2/2]

virtual void WsfL16::Messages::InitialBase::GetLabel	(	int &	aLabel,
		int &	aSubLabel ) const

pure virtual

Referenced by GetClassName(), GetLabel(), GetSubLabel(), InsertContinuationWord(), IsLabelEqual(), WsfL16::MessageSpecialized(), and WriteMessage().

◆ GetMessageLength()

size_t WsfL16::Messages::InitialBase::GetMessageLength ( ) const

inline

Returns the number of extra words in the message.

References mContinuationWords, and mExtensionWords.

Referenced by WsfL16::Messages::Factory::ReadMessage(), and WriteMessage().

◆ GetSubLabel()

int WsfL16::Messages::InitialBase::GetSubLabel ( ) const

inline

References GetLabel().

Referenced by WsfL16::MessageSpecialized().

◆ GetSubWord()

Base * WsfL16::Messages::InitialBase::GetSubWord ( int index ) const

Returns the sub-word with the given index number.

References WsfL16::Messages::Base::Base(), mContinuationWords, and mExtensionWords.

◆ GetWordType()

WordType WsfL16::Messages::InitialBase::GetWordType ( ) const

inlineoverridevirtual

Returns the base type of the word.

Implements WsfL16::Messages::Base.

References WsfL16::Messages::Base::cINITIAL.

◆ Initialize()

bool WsfL16::Messages::InitialBase::Initialize ( const char * aData )

protected

Initialize the message by reading from the data buffer.

◆ InsertContinuationWord()

void WsfL16::Messages::InitialBase::InsertContinuationWord ( std::unique_ptr< ContinuationBase > aContWord )

Inserts a new Continuation word into this word.

References WsfL16::Messages::ContinuationBase::GetLabel(), GetLabel(), and mContinuationWords.

◆ InsertExtensionWord()

void WsfL16::Messages::InitialBase::InsertExtensionWord ( std::unique_ptr< ExtensionBase > aExtensionWord )

Inserts a new Extension word into this word.

References CreateExtensionWord(), WsfL16::Messages::ExtensionBase::GetExtensionNumber(), and mExtensionWords.

Referenced by AddExtensionWord().

◆ IsLabelEqual()

bool WsfL16::Messages::InitialBase::IsLabelEqual	(	int	aLabel,
		int	aSublabel ) const

inline

References GetLabel().

◆ operator=()

const InitialBase & WsfL16::Messages::InitialBase::operator= ( const InitialBase & aRhs )

delete

References InitialBase().

◆ PrintMessage()

void WsfL16::Messages::InitialBase::PrintMessage ( ut::log::MessageStream & aStream ) const

References mContinuationWords, mExtensionWords, and WsfL16::Messages::Base::PrintWord().

Referenced by CreateExtensionWord().

◆ WriteMessage()

void WsfL16::Messages::InitialBase::WriteMessage	(	MessageBitOutput &	aMW,
		bool	aWriteHeader = true ) const

References WsfL16::Messages::Base::cINITIAL, GetLabel(), GetMessageLength(), InitialBase(), mContinuationWords, mExtensionWords, mHeader, WsfL16::Messages::MessageBitOutput::Skip(), WsfL16::Messages::Base::TransferO(), and WsfL16::Messages::MessageBitOutput::Write().

Referenced by WsfL16::Interface::SendJMessage().

◆ Factory

friend class Factory

friend

References Factory.

Referenced by Factory.

Member Data Documentation

◆ mContinuationWords

std::vector<std::unique_ptr<ContinuationBase> > WsfL16::Messages::InitialBase::mContinuationWords

protected

Referenced by AddContinuationWord(), FindContinuation(), GetContinuation(), GetContinuation(), GetContinuationCount(), GetMessageLength(), GetSubWord(), InitialBase(), InsertContinuationWord(), PrintMessage(), and WriteMessage().

◆ mExtensionWords

std::vector<std::unique_ptr<ExtensionBase> > WsfL16::Messages::InitialBase::mExtensionWords

protected

Referenced by GetExtension(), GetExtensionCount(), GetMessageLength(), GetSubWord(), InitialBase(), InsertExtensionWord(), PrintMessage(), and WriteMessage().

◆ mHeader

Header WsfL16::Messages::InitialBase::mHeader

protected

Referenced by GetHeader(), GetHeader(), InitialBase(), and WriteMessage().

The documentation for this class was generated from the following files:
