WsfScriptMessageHandler Class Reference

#include <WsfScriptMessageHandler.hpp>

Collaboration diagram for WsfScriptMessageHandler:

Classes
struct	Handler
	A 'Handler' represents a 'type' and one or more 'subtypes' that share a common script. More...

Public Member Functions
	WsfScriptMessageHandler ()=default
	WsfScriptMessageHandler (WsfScriptContext &aContext)
	WsfScriptMessageHandler (const WsfScriptMessageHandler &aSrc, WsfScriptContext &aContext)
virtual	~WsfScriptMessageHandler ()=default
bool	HasMessageHandler () const
virtual bool	Initialize (double aSimTime, WsfPlatform *aPlatformPtr)
virtual bool	ProcessInput (UtInput &aInput)
virtual bool	ProcessMessage (double aSimTime, const WsfMessage &aMessage)
void	SetTimeAndMessage (double aSimTime, const WsfMessage &aMessage)

Protected Attributes
WsfPlatform *	mPlatformPtr {nullptr}
WsfScriptContext *	mContextPtr {nullptr}
	The context used for compiling and executing scripts.
std::vector< Handler >	mHandlers
	The list of message handlers.
std::vector< WsfStringId >	mScriptNames
	The list of script names, indexed by the handlers script index.
std::vector< UtScript * >	mScriptPtrs
UtScript *	mOnMessageScriptPtr {nullptr}
	The pointer to the explicit 'script void on_message()' if it was defined.
bool	mHasMessageHandler {false}
	true if 'on_message' or 'script void on_message()' has been defined.
UtScriptData *	mMessageVarPtr {nullptr}
	The message script variable's memory index.
int	mMessageVarIndex {-1}

Detailed Description

A script-based message handler.

This object provides the ability to define scripts to process messages. It provides the 'on_message' command and also maintains the 'MESSAGE' script variable that refers to the current message being processed. Any variables defined by WsfScriptContext ('PLATFORM', 'PROCESSOR', 'TIME_NOW') are also available.

The user of this class is responsible for the following:

• Invoking the ProcessInput() method to detect and process the 'on_message' command.
• Invoking the Initialize() method during the platform part Initialize() method.
• Invoking the ProcessMessage() method during the platform part ProcessMessage() method.

Constructor & Destructor Documentation

WsfScriptMessageHandler() [1/3]

WsfScriptMessageHandler::WsfScriptMessageHandler ( )

default

References WsfScriptMessageHandler().

Referenced by WsfScriptMessageHandler(), and WsfScriptMessageHandler().

WsfScriptMessageHandler() [2/3]

WsfScriptMessageHandler::WsfScriptMessageHandler

(

WsfScriptContext &

aContext

)

Constructor

Parameters

aContext

The script context to be used for compiling and executing scripts.

References WsfScriptContext::GetContext(), mContextPtr, mHandlers, mHasMessageHandler, mMessageVarPtr, mOnMessageScriptPtr, mPlatformPtr, mScriptNames, and mScriptPtrs.

WsfScriptMessageHandler() [3/3]

WsfScriptMessageHandler::WsfScriptMessageHandler	(	const WsfScriptMessageHandler &	aSrc,
		WsfScriptContext &	aContext )

Copy constructor

Parameters

aSrc	The source object.
aContext	The script context to be used for compiling and executing scripts.

References WsfScriptContext::GetContext(), mContextPtr, mHandlers, mHasMessageHandler, mMessageVarPtr, mOnMessageScriptPtr, mPlatformPtr, mScriptNames, mScriptPtrs, and WsfScriptMessageHandler().

~WsfScriptMessageHandler()

virtual WsfScriptMessageHandler::~WsfScriptMessageHandler ( )

virtualdefault

Member Function Documentation

HasMessageHandler()

bool WsfScriptMessageHandler::HasMessageHandler ( ) const

inline

Return true if there is a message handler defined.

Note

This is valid only after Initialize() has been called.

References mHasMessageHandler.

Initialize()

bool WsfScriptMessageHandler::Initialize ( double aSimTime, WsfPlatform * aPlatformPtr )

virtual

Initialize the message handler object.

Parameters

aSimTime	The current simulation time.
aPlatformPtr	The platform with which the message handler is associated.

References mContextPtr, mHandlers, mHasMessageHandler, mOnMessageScriptPtr, mPlatformPtr, mScriptNames, mScriptPtrs, and ok.

ProcessInput()

bool WsfScriptMessageHandler::ProcessInput ( UtInput & aInput )

virtual

Check for and process message handler commands.

Parameters

aInput

The input stream.

Returns

'true' if the command was recognized (and processed) or 'false' if the command was not one recognized by this class.

References mContextPtr, mHandlers, WsfScriptMessageHandler::Handler::mScriptIndex, mScriptNames, and WsfScriptMessageHandler::Handler::mType.

ProcessMessage()

bool WsfScriptMessageHandler::ProcessMessage ( double aSimTime, const WsfMessage & aMessage )

virtual

Invoke the appropriate message handling script if one is defined. If a script has been defined for the message then:

• Set TIME_NOW to the current simulation time.
• Set MESSAGE to refer to the message.
• Invoke the message handling script.

  Parameters

  aSimTime	The current simulation time.
  aMessage	The message being processed.

  Returns

  'true' if a message handler was defined for the message or 'false' if not.

References WsfMessage::GetSubType(), WsfMessage::GetType(), mContextPtr, mHandlers, mHasMessageHandler, mMessageVarPtr, mOnMessageScriptPtr, mPlatformPtr, mScriptPtrs, and SetTimeAndMessage().

Referenced by WsfSA_Perceive::ProcessMessage(), and WsfTrackProcessor::ProcessMessage().

SetTimeAndMessage()

void WsfScriptMessageHandler::SetTimeAndMessage	(	double	aSimTime,
		const WsfMessage &	aMessage )

Set the TIME_NOW and MESSAGE script variables.

Parameters

aSimTime	The current simulation time.
aMessage	The message that is being processed.

References mMessageVarPtr.

Referenced by ProcessMessage().

Member Data Documentation

mContextPtr

WsfScriptContext* WsfScriptMessageHandler::mContextPtr {nullptr}

protected

The context used for compiling and executing scripts.

Referenced by Initialize(), ProcessInput(), ProcessMessage(), WsfScriptMessageHandler(), and WsfScriptMessageHandler().

mHandlers

std::vector<Handler> WsfScriptMessageHandler::mHandlers

protected

The list of message handlers.

Referenced by Initialize(), ProcessInput(), ProcessMessage(), WsfScriptMessageHandler(), and WsfScriptMessageHandler().

mHasMessageHandler

bool WsfScriptMessageHandler::mHasMessageHandler {false}

protected

true if 'on_message' or 'script void on_message()' has been defined.

Referenced by HasMessageHandler(), Initialize(), ProcessMessage(), WsfScriptMessageHandler(), and WsfScriptMessageHandler().

mMessageVarIndex

int WsfScriptMessageHandler::mMessageVarIndex {-1}

protected

mMessageVarPtr

UtScriptData* WsfScriptMessageHandler::mMessageVarPtr {nullptr}

protected

The message script variable's memory index.

Referenced by ProcessMessage(), SetTimeAndMessage(), WsfScriptMessageHandler(), and WsfScriptMessageHandler().

mOnMessageScriptPtr

UtScript* WsfScriptMessageHandler::mOnMessageScriptPtr {nullptr}

protected

The pointer to the explicit 'script void on_message()' if it was defined.

Referenced by Initialize(), ProcessMessage(), WsfScriptMessageHandler(), and WsfScriptMessageHandler().

mPlatformPtr

WsfPlatform* WsfScriptMessageHandler::mPlatformPtr {nullptr}

protected

Referenced by Initialize(), ProcessMessage(), WsfScriptMessageHandler(), and WsfScriptMessageHandler().

mScriptNames

std::vector<WsfStringId> WsfScriptMessageHandler::mScriptNames

protected

The list of script names, indexed by the handlers script index.

Referenced by Initialize(), ProcessInput(), WsfScriptMessageHandler(), and WsfScriptMessageHandler().

mScriptPtrs

std::vector<UtScript*> WsfScriptMessageHandler::mScriptPtrs

protected

The list of scripts, indexed by the handles script index. This is valid only after Initialize() has been called. The scripts are owned by the script context.

Referenced by Initialize(), ProcessMessage(), WsfScriptMessageHandler(), and WsfScriptMessageHandler().

---

The documentation for this class was generated from the following files:

• WsfScriptMessageHandler.hpp
• WsfScriptMessageHandler.cpp
