An object that represents the optical signature of a platform. More...

#include <WsfOpticalSignature.hpp>

Inheritance diagram for WsfOpticalSignature:

[legend]

Collaboration diagram for WsfOpticalSignature:

[legend]

Public Types
enum	{ cSIGNATURE_INDEX = 1 }
Public Types inherited from WsfObject
typedef std::vector< WsfStringId >	TypeList
	The list of types returned by GetTypeList.

Public Member Functions
	WsfOpticalSignature ()
WsfOpticalSignature *	Clone () const override=0
virtual float	GetSignature (double aSimTime, WsfStringId aStateId, double aAzimuth, double aElevation)=0
Public Member Functions inherited from WsfSignature
	WsfSignature ()
	WsfSignature (const WsfSignature &aSrc)
WsfSignature &	operator= (const WsfSignature &)=delete
	~WsfSignature () override=default
virtual bool	InitializeType ()
virtual bool	Initialize (double aSimTime, WsfPlatform *aPlatformPtr)
virtual bool	IsA_ValidState (WsfStringId aId) const
virtual std::vector< WsfStringId >	GetStateNames () const
	get the list of all valid states belonging to the signature
bool	ProcessInput (UtInput &aInput) override
bool	RequiresPlatform () const
	indicates that a signature can be queried without a valid mPlatform
Public Member Functions inherited from WsfObject
	WsfObject ()
	This is the constructor for the WsfObject class.
	~WsfObject () override
	This is the destructor for the WsfObject class.
const char *	GetScriptClassName () const override
const std::string &	GetType () const
WsfStringId	GetTypeId () const
	Get the string ID of the 'type' of the object.
void	SetType (WsfStringId aType)
const std::string &	GetBaseType () const
WsfStringId	GetBaseTypeId () const
const TypeList &	GetTypeList () const
bool	IsA_TypeOf (WsfStringId aType) const
WsfObject &	operator= (const WsfObject &aRhs)
	Assignment operator.
template<typename T>
void	Serialize (T &aBuff)
	For XIO (de)serialization.
const std::string &	GetName () const
WsfStringId	GetNameId () const
void	SetName (WsfStringId aName)

New interface methods to get the projected area and radiant intensity.
These methods may be implemented by derived implementations to provide a more complete implementation of the 'signature' within the optical spectrum.
using	BandList = std::vector<WsfEM_Types::OpticalBand>
virtual bool	GetProjectedArea (double aSimTime, WsfStringId aStateId, double aAzimuth, double aElevation, double &aProjectedArea)
virtual bool	GetRadiantIntensity (double aSimTime, WsfStringId aState, const BandList &aBands, double aAzimuth, double aElevation, double &aRadiantIntensity)
bool	UsesInherentContrast () const

Methods to support the actual interface on the platform.
These methods provide the interface from the sensor model to the signature. The user makes calls like WsfOpticalSignature::GetSignature(...).
static WsfStringId	GetInputType (WsfPlatform *aPlatformPtr)
static WsfStringId	GetState (WsfPlatform *aPlatformPtr)
static bool	SetState (WsfPlatform *aPlatformPtr, WsfStringId aState)
static float	GetScaleFactor (WsfPlatform *aPlatformPtr)
static bool	SetScaleFactor (WsfPlatform *aPlatformPtr, float aScaleFactor)
static float	GetValue (double aSimTime, WsfPlatform *aPlatformPtr, double aAzimuth, double aElevation)
static bool	GetProjectedArea (double aSimTime, WsfPlatform *aPlatformPtr, double aAzimuth, double aElevation, double &aProjectedArea)
static bool	GetRadiantIntensity (double aSimTime, WsfPlatform *aPlatformPtr, const BandList &aBands, double aAzimuth, double aElevation, double &aRadiantIntensity)
static bool	UsesInherentContrast (WsfPlatform *aPlatformPtr)
static void	RegisterScriptMethods (UtScriptTypes &aScriptTypes)
static void	RegisterInterface (WsfScenario &aScenario)
	Register the platform interface object on the prototype signature list in the specified scenario.
void	SetInherentContrast (bool aContrast)

Additional Inherited Members
	WsfObject (const WsfObject &aSrc)
	Copy constructor (for Clone()).
Static Protected Member Functions inherited from WsfSignature
template<class SignatureState, WsfStringId SignatureState::* IdMember, typename Iterator>
static std::vector< WsfStringId >	GetStateNamesP (Iterator aBegin, Iterator aEnd)
Protected Attributes inherited from WsfSignature
WsfPlatform *	mPlatformPtr
double	mBaseTime
bool	mRequiresPlatform {false}

Detailed Description

An object that represents the optical signature of a platform.

Member Typedef Documentation

◆ BandList

using WsfOpticalSignature::BandList = std::vector<WsfEM_Types::OpticalBand>

Member Enumeration Documentation

◆ anonymous enum

anonymous enum

Enumerator
cSIGNATURE_INDEX	Index of signature within WsfSignatureList (must be unique).

Constructor & Destructor Documentation

◆ WsfOpticalSignature()

WsfOpticalSignature::WsfOpticalSignature ( )

References WsfSignature::WsfSignature().

Referenced by WsfCompositeOpticalSignature::Clone(), Clone(), WsfSpaceOpticalSignature::Clone(), WsfStandardOpticalSignature::Clone(), GetProjectedArea(), GetRadiantIntensity(), GetValue(), WsfCompositeOpticalSignature::ObjectFactory(), WsfSpaceOpticalSignature::ObjectFactory(), WsfStandardOpticalSignature::ObjectFactory(), WsfCompositeOpticalSignature::operator=(), WsfSpaceOpticalSignature::operator=(), UsesInherentContrast(), WsfCompositeOpticalSignature::WsfCompositeOpticalSignature(), WsfCompositeOpticalSignature::WsfCompositeOpticalSignature(), WsfSpaceOpticalSignature::WsfSpaceOpticalSignature(), WsfSpaceOpticalSignature::WsfSpaceOpticalSignature(), and WsfStandardOpticalSignature::WsfStandardOpticalSignature().

Member Function Documentation

◆ Clone()

WsfOpticalSignature * WsfOpticalSignature::Clone ( ) const

overridepure virtual

Return a copy of this object. Must be implemented by all derived types. If cloning is impossible, a WsfUncloneableException should be thrown.

Implements WsfObject.

Implemented in WsfCompositeOpticalSignature, WsfSpaceOpticalSignature, and WsfStandardOpticalSignature.

References WsfOpticalSignature().

◆ GetInputType()

WsfStringId WsfOpticalSignature::GetInputType ( WsfPlatform * aPlatformPtr )

static

Get the input type of the signature.

Parameters

aPlatformPtr [input] The pointer to the platform containing the signature.

Returns: The current signature state.

References cSIGNATURE_INDEX, WsfSignatureList::GetInputType(), and WsfPlatform::GetSignatureList().

◆ GetProjectedArea() [1/2]

bool WsfOpticalSignature::GetProjectedArea	(	double	aSimTime,
		WsfPlatform *	aPlatformPtr,
		double	aAzimuth,
		double	aElevation,
		double &	aProjectedArea )

static

Get the projected area of the platform from a specified aspect angle.

Parameters

aSimTime	[input] The current simulation time.
aPlatformPtr	[input] The platform from which the projected area is to be retrieved.
aAzimuth	[input] azimuth of the observer with respect to this platform (radians).
aElevation	[input] elevation of the observer with respect to this platform (radians).
aProjectedArea	[output] The projected area of platform (m^2).

Returns: true if successful, false if not.

References cSIGNATURE_INDEX, GetProjectedArea(), WsfPlatform::GetSignatureList(), GetValue(), and WsfOpticalSignature().

◆ GetProjectedArea() [2/2]

bool WsfOpticalSignature::GetProjectedArea	(	double	aSimTime,
		WsfStringId	aStateId,
		double	aAzimuth,
		double	aElevation,
		double &	aProjectedArea )

virtual

Reimplemented in WsfCompositeOpticalSignature, and WsfSpaceOpticalSignature.

Referenced by GetProjectedArea(), and GetSignature().

◆ GetRadiantIntensity() [1/2]

bool WsfOpticalSignature::GetRadiantIntensity	(	double	aSimTime,
		WsfPlatform *	aPlatformPtr,
		const BandList &	aBands,
		double	aAzimuth,
		double	aElevation,
		double &	aRadiantIntensity )

static

Get the radiant intensity of the platform within a specified band from a specified aspect angle.

Parameters

aSimTime	[input] The current simulation time.
aPlatformPtr	[input] The platform from which the radiant intensity is to be retrieved.
aBands	[input] The list of bands that represent the region of interest within the the optical spectrum.
aAzimuth	[input] azimuth of the observer with respect to this platform (radians).
aElevation	[input] elevation of the observer with respect to this platform (radians).
aRadiantIntensity	[output] The radiant intensity of platform (W/sr).

Returns: true if successful, false if not.

References cSIGNATURE_INDEX, GetRadiantIntensity(), WsfPlatform::GetSignatureList(), ok, and WsfOpticalSignature().

◆ GetRadiantIntensity() [2/2]

bool WsfOpticalSignature::GetRadiantIntensity	(	double	aSimTime,
		WsfStringId	aState,
		const BandList &	aBands,
		double	aAzimuth,
		double	aElevation,
		double &	aRadiantIntensity )

virtual

Reimplemented in WsfCompositeOpticalSignature, and WsfSpaceOpticalSignature.

Referenced by WsfEOIR_IRST_SensorMode::AttemptToDetectInfrared(), WsfEOIR_IRST_SensorMode::AttemptToDetectVisual(), and GetRadiantIntensity().

◆ GetScaleFactor()

float WsfOpticalSignature::GetScaleFactor ( WsfPlatform * aPlatformPtr )

static

Get the signature scale factor.

Parameters

aPlatformPtr [input] The pointer to the platform containing the signature.

Returns: The signature scale factor.

References cSIGNATURE_INDEX, WsfSignatureList::GetScaleFactor(), and WsfPlatform::GetSignatureList().

◆ GetSignature()

virtual float WsfOpticalSignature::GetSignature	(	double	aSimTime,
		WsfStringId	aStateId,
		double	aAzimuth,
		double	aElevation )

pure virtual

Get the optical signature for a given set of conditions.

Parameters

aSimTime	[input] The current simulation time.
aStateId	[input] The string ID representing the signature state to be used.
aAzimuth	[input] The azimuth of the observer with respect to the target.
aElevation	[input] The elevation of the observer with respect to the target.

Returns: The optical cross section (m^2)

Implemented in WsfCompositeOpticalSignature, WsfSpaceOpticalSignature, and WsfStandardOpticalSignature.

References GetProjectedArea().

Referenced by GetValue().

◆ GetState()

WsfStringId WsfOpticalSignature::GetState ( WsfPlatform * aPlatformPtr )

static

Get the current signature state.

Parameters

aPlatformPtr [input] The pointer to the platform containing the signature.

Returns: The current signature state.

References cSIGNATURE_INDEX, WsfPlatform::GetSignatureList(), and WsfSignatureList::GetState().

◆ GetValue()

float WsfOpticalSignature::GetValue	(	double	aSimTime,
		WsfPlatform *	aPlatformPtr,
		double	aAzimuth,
		double	aElevation )

static

Get the signature value for a set of conditions.

Parameters

aSimTime	[input] The current simulation time.
aPlatformPtr	[input] The platform from which the signature is to be retrieved.
aAzimuth	[input] azimuth of the observer with respect to this platform (radians).
aElevation	[input] elevation of the observer with respect to this platform (radians).

Returns: The optical signature.

References cSIGNATURE_INDEX, WsfPlatform::GetHeight(), WsfPlatform::GetLength(), WsfObject::GetName(), GetSignature(), WsfPlatform::GetSignatureList(), WsfObject::GetType(), WsfPlatform::GetWidth(), and WsfOpticalSignature().

Referenced by WsfBeamDirector::WsfBeamDirectorMode::AttemptToDetect(), WsfEOIR_Sensor::EOIR_Mode::AttemptToDetect(), WsfLADAR_Sensor::LADAR_Mode::AttemptToDetect(), WsfOpticalSensor::OpticalMode::AttemptToDetect(), WsfSAR_Sensor::SAR_Mode::AttemptToDetect(), WsfEOIR_IRST_SensorMode::AttemptToDetectInfrared(), WsfEOIR_IRST_SensorMode::AttemptToDetectVisual(), and GetProjectedArea().

◆ RegisterInterface()

void WsfOpticalSignature::RegisterInterface ( WsfScenario & aScenario )

static

Register the platform interface object on the prototype signature list in the specified scenario.

References WsfSignatureList::AddInterface(), cSIGNATURE_INDEX, and WsfScenario::GetSignatureListPrototype().

Referenced by WsfOpticalSignatureTypes::WsfOpticalSignatureTypes().

◆ RegisterScriptMethods()

void WsfOpticalSignature::RegisterScriptMethods ( UtScriptTypes & aScriptTypes )

static

Register the script methods associated with this class.

Note: The WsfPlatform script class must be defined before calling this method.

Referenced by WsfMilScriptExtensions::ExtendScriptClasses().

◆ SetInherentContrast()

void WsfOpticalSignature::SetInherentContrast ( bool aContrast )

inlineprotected

Referenced by WsfSpaceOpticalSignature::WsfSpaceOpticalSignature().

◆ SetScaleFactor()

bool WsfOpticalSignature::SetScaleFactor	(	WsfPlatform *	aPlatformPtr,
		float	aScaleFactor )

static

Set the signature scale factor.

Parameters

aPlatformPtr	[input] The pointer to the platform containing the signature.
aScaleFactor	[input] The new signature scale factor.

Returns: true if successful, false if and error occurred.

References cSIGNATURE_INDEX, WsfPlatform::GetSignatureList(), and WsfSignatureList::SetScaleFactor().

◆ SetState()

bool WsfOpticalSignature::SetState	(	WsfPlatform *	aPlatformPtr,
		WsfStringId	aState )

static

Set the signatures state

Parameters

aPlatformPtr	[input] The pointer to the platform containing the signature.
aState	[input] The new signatures state.

Returns: true if successful, false if and error occurred.

References cSIGNATURE_INDEX, WsfPlatform::GetSignatureList(), and WsfSignatureList::SetState().

◆ UsesInherentContrast() [1/2]

bool WsfOpticalSignature::UsesInherentContrast ( ) const

inline

Referenced by WsfOpticalSensor::OpticalMode::AttemptToDetect(), and WsfEOIR_IRST_SensorMode::AttemptToDetectVisual().

◆ UsesInherentContrast() [2/2]

bool WsfOpticalSignature::UsesInherentContrast ( WsfPlatform * aPlatformPtr )

static

Returns whether the signature of the platform uses inherent_contrast, or ignores it.

Parameters

aPlatformPtr [input] The platform from which the signature is pulled.

Returns: true if the signature uses inherent_contrast

References cSIGNATURE_INDEX, WsfSignatureList::GetInterface(), WsfPlatform::GetSignatureList(), and WsfOpticalSignature().

The documentation for this class was generated from the following files:

Public Types

Public Member Functions

New interface methods to get the projected area and radiant intensity.

Methods to support the actual interface on the platform.

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ BandList

Member Enumeration Documentation

◆ anonymous enum

Constructor & Destructor Documentation

◆ WsfOpticalSignature()

Member Function Documentation

◆ Clone()

◆ GetInputType()

◆ GetProjectedArea() [1/2]

◆ GetProjectedArea() [2/2]

◆ GetRadiantIntensity() [1/2]

◆ GetRadiantIntensity() [2/2]

◆ GetScaleFactor()

◆ GetSignature()

◆ GetState()

◆ GetValue()

◆ RegisterInterface()

◆ RegisterScriptMethods()

◆ SetInherentContrast()

◆ SetScaleFactor()

◆ SetState()

◆ UsesInherentContrast() [1/2]

◆ UsesInherentContrast() [2/2]
