WsfExtInput Class Reference

#include <WsfExtInterface.hpp>

Inheritance diagram for WsfExtInput:

Collaboration diagram for WsfExtInput:

Public Member Functions
	WsfExtInput (WsfScenario &aScenario)
	~WsfExtInput () override
void	SimulationCreated (WsfSimulation &aSimulation) override
bool	Complete () override
virtual bool	ProcessExtInput (UtInput &aInput)
WsfExtEmission *	GetEmission ()
void	AddedToScenario () override
Public Member Functions inherited from WsfScenarioExtension
	WsfScenarioExtension ()
	~WsfScenarioExtension () override
WsfScenario &	GetScenario () const
WsfApplication &	GetApplication () const
virtual bool	ProcessInput (UtInput &aInput)
virtual void	FileLoaded (const std::string &aFileName)
virtual bool	Complete2 ()
virtual bool	AlwaysCreate ()
Public Member Functions inherited from WsfExtension
virtual	~WsfExtension ()=default
const std::string &	GetExtensionName () const

Static Public Member Functions
static WsfExtInput *	Find (const WsfScenario &aScenario)

Public Attributes
WsfExtData	mData

Additional Inherited Members
Protected Member Functions inherited from WsfExtension
void	InitializeExtensionName (const std::string &aName)

Constructor & Destructor Documentation

WsfExtInput()

WsfExtInput::WsfExtInput

(

WsfScenario &

aScenario

)

References mData, and WsfScenarioExtension::WsfScenario.

Referenced by Find().

~WsfExtInput()

WsfExtInput::~WsfExtInput ( )

override

Member Function Documentation

AddedToScenario()

void WsfExtInput::AddedToScenario ( )

overridevirtual

Called when the extension has been added to the scenario. This is typically used to register new component type objects and object factories, e.g.:

WsfScenario& scenario(GetScenario());
WsfMoverTypes::Get(scenario).AddCoreType("MY_MOVER", new MyMover(scenario));
WsfAntennaPatterTypes::Get(scenario).AddObjectFactor(MyAntennaPattern::ObjectFactory);

Script classes must NOT be registered here because they are global to the entire application. They should be registered in WsfApplication::AddedToApplication.

Note

GetScenario() and GetApplication() are now valid.

Reimplemented from WsfScenarioExtension.

Complete()

bool WsfExtInput::Complete ( )

overridevirtual

Called when all inputs are processed. This is called when the application calls WsfScenario::LoadComplete to signify that all input data has been loaded into the scenario. The extension should perform any additional validity checking or other processing on its input data. Constant data may be created and stored here. Unless Complete2() is also implement, the contents of this class should not be changed after this call.

The extension should not assume anything about the state of another extension unless this a dependency has been registered to ensure the other extension has been called prior to this, e.g.:

app.ExtensionDepends("my_ext", "other_ext");

Returns

'true' if no problems or 'false' if an error occurred that would prevent execution.

Reimplemented from WsfScenarioExtension.

References WsfScenarioExtension::GetScenario(), and mData.

Find()

WsfExtInput * WsfExtInput::Find ( const WsfScenario & aScenario )

static

References WsfScenario::FindExtension(), WsfExtInput(), and WsfScenarioExtension::WsfScenario.

Referenced by WsfMilExtension::AddedToScenario(), WsfMilExtInterface::PrintEmitterTypes(), and WsfMilExtInterface::ProcessInput().

GetEmission()

WsfExtEmission * WsfExtInput::GetEmission ( )

inline

References mData.

Referenced by WsfMilExtInterface::PrintEmitterTypes().

ProcessExtInput()

virtual bool WsfExtInput::ProcessExtInput ( UtInput & aInput )

inlinevirtual

Process input from client input blocks (DIS, HLA).

Note

This method name is intentionally different from ProcessInput. We do not want the scenario to process input for the Ext interface, as it could be at the global level.

References WsfScenarioExtension::GetScenario(), and mData.

Referenced by WsfDisInput::ProcessDeviceInput().

SimulationCreated()

void WsfExtInput::SimulationCreated ( WsfSimulation & aSimulation )

overridevirtual

Called when a simulation has been created. (Technically this is called upon entry to WsfSimulation::Initialize()). This is typically used when a scenario extension also requires a simulation extension. The method would typically register the simulation extension as follows:

aSimulation.RegisterExtension("my_ext", new MySimulationExtension());

Parameters

aSimulation

The simulation that is being created. See note below!

Note

This is called upon entry to WsfSimulation::Initialize() and nothing can be assumed about the state of the simulation.

See also

WsfSimulationExtension, WsfApplicationExtension::SimulationCreated

Reimplemented from WsfScenarioExtension.

References WsfExtension::GetExtensionName(), and WsfSimulation::RegisterExtension().

Member Data Documentation

mData

WsfExtData WsfExtInput::mData

Referenced by WsfMilExtension::AddedToScenario(), Complete(), GetEmission(), ProcessExtInput(), WsfMilExtInterface::ProcessInput(), and WsfExtInput().

---

The documentation for this class was generated from the following files:

• WsfExtInterface.hpp
• WsfExtInterface.cpp
