This implementation is decoupled from the weapon class to handle only laser-related effects, including propagation and engagement. More...

#include <WsfHighEnergyLaser.hpp>

Inheritance diagram for WsfHighEnergyLaser:

[legend]

Collaboration diagram for WsfHighEnergyLaser:

[legend]

Public Member Functions
	WsfHighEnergyLaser (WsfScenario &aScenario)
	WsfHighEnergyLaser (const WsfHighEnergyLaser &aSrc)
WsfHighEnergyLaser &	operator= (const WsfHighEnergyLaser &)=delete
	~WsfHighEnergyLaser () override=default
WsfDirectedEnergyWeapon::Beam *	Clone () const override=0
	Clone this object.
bool	ProcessInput (UtInput &aInput) override
virtual bool	Initialize (WsfDirectedEnergyWeapon *aWeaponPtr)
virtual void	OutputConfiguration () const
WsfDirectedEnergyWeapon *	GetWeapon () const
virtual void	BeginLasing (double aSimTime, size_t aTargetIndex, const std::string &aTargetOffsetName="")
void	UpdateLasing (double aSimTime)
virtual void	EndLasing (double aSimTime)
bool	IsLasing () const
	Return whether the weapon is currently lasing.
double	GetIncidenceAngle () const override
	Return the incidence angle of the laser on the target.
virtual bool	TargetOccluded () const
virtual bool	TestLasing (double aDuration, size_t aTargetIndex, const std::string &aTargetOffset="")
virtual bool	TestLasing (double aDuration, const WsfGeoPoint &aSourceLocation, const WsfGeoPoint &aTargetLocation)
virtual double	RequiredDurationEnergy (double aEnergy, const WsfGeoPoint &aSourceLocation, const WsfGeoPoint &aTargetLocation)
virtual double	RequiredDurationFluence (double aEnergyDensity, const WsfGeoPoint &aSourceLocation, const WsfGeoPoint &aTargetLocation)
virtual double	RequiredDurationEnergy (double aEnergy, int aTargetIndex, const std::string &aTargetOffset="")
virtual double	RequiredDurationFluence (double aEnergyDensity, size_t aTargetIndex, const std::string &aTargetOffset="")
virtual bool	UpdateEngagementGeometry (double aSimTime, size_t aTargetIndex, const std::string &aTargetOffset="", bool aAddJitter=true)
double	GetDamageRadius () const
double	GetDefaultDamageRadius () const
virtual void	SetDamageRadius (double aDamageRadius)
virtual void	SetAtmosphericStructure (const std::string &aAtmosphericStructure)
double	GetJitter () const
	Get the expected value for the jitter of the HEL on target.
void	SetJitter (double aJitter)
	Set the expected value for the jitter of the HEL on target.
size_t	GetTargetIndex () const
	Get the current target index (valid only while IsLasing is true).
double	GetTargetRange () const
	Get the current range to target (only valid while IsLasing is true).
void	SetBeamQuality (double aBeamQuality)
	Set the beam quality wrt a perfect Gaussian beam.
virtual double	GetWindowStrehl () const
	Get the strehl due to window effects (default is 1.0 [no effect]).
virtual void	SetWindowStrehl (double aWindowStrehl)
	Set the window strehl (should be between 0 and 1).
virtual double	GetAeroStrehl () const
	Get the aero strehl (strehl from aerooptics; should be between 0 and 1).
virtual void	SetAeroStrehl (double aAeroStrehl)
	Set the areo strehl (strehl from aerooptics; should be between 0 and 1).
virtual double	GetSystemStrehl () const
	Get the total rms strehl from all sources.
virtual void	SetSystemStrehl (double aSystemStrehl)
	Set the total rms system strehl.
virtual double	GetSystemTransmission () const
	Get the system transmission, if available (default is 1.0).
WsfSimulation *	GetSimulation () const
Public Member Functions inherited from WsfDirectedEnergyWeapon::Beam
	Beam ()
	Beam (const Beam &aSrc)
Beam &	operator= (const Beam &)=delete
	~Beam () override=default
void	Initialize ()
	Initialize the beam structure elements to initial values.
double	GetPeakFluence () const
	Return the peak fluence (i.e., the peak irradiance on target integrated over time).
void	SetPeakFluence (double aPeakFluence)
	Set the peak fluence, in W/m^2.
double	GetEdgeFluence () const
void	SetEdgeFluence (double aEdgeFluence)
	Set the edge fluence, in W/m^2.
double	GetEdgeRadius () const
	Return the edge radius (i.e., the radius at which the edge fluence is calculated).
void	SetEdgeRadius (double aEdgeRadius)
	Set the edge radius (i.e., the radius at which the edge fluence is calculated).
double	GetSemiMinorAxis () const
	Same as GetEdgeRadius, above.
void	SetSpotRadius (double aRadius)
	Set the spot radius, which for an elliptical spot is the same as the semi-minor axis.
double	GetSpotRadius () const
	Return the spot radius, which for an elliptical spot is the same as the semi-minor axis.
double	GetSemiMajorAxis () const
virtual void	SetIncidenceAngle (double aIncidenceAngle)
	Set the incidence angle of the beam on target, with respect to the normal to the target's surface at the spot center.
virtual double	GetWavelength () const
	Return the characteristic wavelength of the beam.
unsigned	GetWavelength_nm () const
	Return the characteristic wavelength of the beam as a string in nm.
virtual void	SetWavelength (double aWavelength)
	Set the characteristic wavelength.
virtual double	GetApertureDiameter () const
	Return the diameter of the exit aperture of the beam producing the spot.
virtual void	SetApertureDiameter (double aApertureDiameter)
	Set the diameter of the aperture through which the beam exits (m^2).
virtual double	GetInitialPower () const
	Return the initial power of the beam before any losses.
virtual void	SetInitialPower (double aInitialPower)
	Set initial power of the beam before any losses.
double	GetPeakIrradiance () const
	Return the average irradiance.
void	SetPeakIrradiance (double aPeakIrradiance)
	Set the peak irradiance (W/m^2).
double	GetAverageIrradiance () const
	Return the average irradiance over the beam spot (W/m2).
void	SetAverageIrradiance (double aAverageIrradiance)
	Set the average irradiance over the beam spot.
double	GetEdgeIrradiance () const
	Return the average irradiance over the beam spot (W/m2).
void	SetEdgeIrradiance (double aEdgeIrradiance)
	Set the average irradiance over the beam spot.
virtual double	GetPulseRepetitionFrequency () const
	Return the Pulse Repetition Frequency.
virtual void	SetPulseRepetitionFrequency (double aPRF)
	Set the pulse repetition frequency.
virtual double	GetPulseWidth () const
	Return the Pulse Width.
virtual void	SetPulseWidth (double aPulseWidth)
	Set the pulse width (0 == CW).
virtual double	GetEnergyDensity () const
double	GetEnergy () const
	Return the total energy (i.e., the average irradiance on target integrated over time and area; J).
void	SetEnergy (double aEnergy)
	Set the energy deposited during the engagement in the beam spot (J).
double	GetAveragePower () const
	Return the average power on target, integrated over the beam spot.
void	SetAveragePower (double aAveragePower)
	Set the average power on target, integrated over the beam spot.
void	GetOffsetLocationECS (double aLocationECS[3]) const
	Get the beam's offset location in target entity coordinates.
void	SetOffsetLocationECS (const double aLocationECS[3])
	Set the beam's offset location in target entity coordinates.
Public Member Functions inherited from WsfObject
	WsfObject ()
	This is the constructor for the WsfObject class.
	~WsfObject () override
	This is the destructor for the WsfObject class.
const char *	GetScriptClassName () const override
const std::string &	GetType () const
WsfStringId	GetTypeId () const
	Get the string ID of the 'type' of the object.
void	SetType (WsfStringId aType)
const std::string &	GetBaseType () const
WsfStringId	GetBaseTypeId () const
const TypeList &	GetTypeList () const
bool	IsA_TypeOf (WsfStringId aType) const
WsfObject &	operator= (const WsfObject &aRhs)
	Assignment operator.
template<typename T>
void	Serialize (T &aBuff)
	For XIO (de)serialization.
const std::string &	GetName () const
WsfStringId	GetNameId () const
void	SetName (WsfStringId aName)

Protected Member Functions
void	Propagate (double aSimTime) override=0
	WsfObject (const WsfObject &aSrc)
	Copy constructor (for Clone()).

Protected Attributes
WsfDirectedEnergyWeapon *	mWeaponPtr
bool	mSysInit
	The weapon object associated with the HEL.
bool	mCalculateIncidence
double	mIncidenceAngle
size_t	mTargetIndex
WsfStringId	mTargetOffsetName
bool	mTargetOccluded
double	mTargetRange
bool	mIsLasing
bool	mDebug
double	mLastUpdateTime
double	mDamageRadius
double	mDefaultDamageRadius
double	mJitterExpectedValue
double	mBeamQuality
wsf::AtmosphericTurbulence	mTurbulenceModel

Additional Inherited Members
Public Types inherited from WsfObject
typedef std::vector< WsfStringId >	TypeList
	The list of types returned by GetTypeList.

Detailed Description

This implementation is decoupled from the weapon class to handle only laser-related effects, including propagation and engagement.

Constructor & Destructor Documentation

◆ WsfHighEnergyLaser() [1/2]

WsfHighEnergyLaser::WsfHighEnergyLaser ( WsfScenario & aScenario )

◆ WsfHighEnergyLaser() [2/2]

WsfHighEnergyLaser::WsfHighEnergyLaser ( const WsfHighEnergyLaser & aSrc )

References WsfDirectedEnergyWeapon::Beam::Beam(), mBeamQuality, mCalculateIncidence, mDamageRadius, mDebug, mDefaultDamageRadius, mIncidenceAngle, mIsLasing, mJitterExpectedValue, mLastUpdateTime, mSysInit, mTargetIndex, mTargetOccluded, mTargetOffsetName, mTargetRange, mTurbulenceModel, mWeaponPtr, and WsfHighEnergyLaser().

◆ ~WsfHighEnergyLaser()

WsfHighEnergyLaser::~WsfHighEnergyLaser ( )

overridedefault

Member Function Documentation

◆ BeginLasing()

void WsfHighEnergyLaser::BeginLasing	(	double	aSimTime,
		size_t	aTargetIndex,
		const std::string &	aTargetOffsetName = "" )

virtual

References mIsLasing, mLastUpdateTime, mTargetIndex, mTargetOffsetName, and UpdateLasing().

◆ Clone()

WsfDirectedEnergyWeapon::Beam * WsfHighEnergyLaser::Clone ( ) const

overridepure virtual

Clone this object.

Reimplemented from WsfDirectedEnergyWeapon::Beam.

Implemented in WsfDefaultHEL.

Referenced by WsfHighEnergyLaserTypes::Create().

◆ EndLasing()

void WsfHighEnergyLaser::EndLasing ( double aSimTime )

virtual

References mIsLasing, and mTargetIndex.

◆ GetAeroStrehl()

virtual double WsfHighEnergyLaser::GetAeroStrehl ( ) const

inlinevirtual

Get the aero strehl (strehl from aerooptics; should be between 0 and 1).

◆ GetDamageRadius()

double WsfHighEnergyLaser::GetDamageRadius ( ) const

inline

Get the max. radius about which the laser is effective.

Note: If the value is zero, the damage radius is ignored, and the spot edge is used instead.

References mDamageRadius.

◆ GetDefaultDamageRadius()

double WsfHighEnergyLaser::GetDefaultDamageRadius ( ) const

inline

Get the max. radius about which the laser is effective (default value).

Note: If the value is zero, the damage radius is ignored, and the spot edge is used instead.; This accessor is meant to support legacy operation, where only one damage radius is specified.

References mDefaultDamageRadius.

◆ GetIncidenceAngle()

double WsfHighEnergyLaser::GetIncidenceAngle ( ) const

inlineoverridevirtual

Return the incidence angle of the laser on the target.

Reimplemented from WsfDirectedEnergyWeapon::Beam.

References mIncidenceAngle.

◆ GetJitter()

double WsfHighEnergyLaser::GetJitter ( ) const

inline

Get the expected value for the jitter of the HEL on target.

References mJitterExpectedValue.

◆ GetSimulation()

WsfSimulation * WsfHighEnergyLaser::GetSimulation ( ) const

References mWeaponPtr.

Referenced by WsfDefaultHEL::Propagate(), and UpdateEngagementGeometry().

◆ GetSystemStrehl()

virtual double WsfHighEnergyLaser::GetSystemStrehl ( ) const

inlinevirtual

Get the total rms strehl from all sources.

◆ GetSystemTransmission()

virtual double WsfHighEnergyLaser::GetSystemTransmission ( ) const

inlinevirtual

Get the system transmission, if available (default is 1.0).

◆ GetTargetIndex()

size_t WsfHighEnergyLaser::GetTargetIndex ( ) const

inline

Get the current target index (valid only while IsLasing is true).

References mTargetIndex.

◆ GetTargetRange()

double WsfHighEnergyLaser::GetTargetRange ( ) const

inline

Get the current range to target (only valid while IsLasing is true).

References mTargetRange.

Referenced by WsfDefaultHEL::Propagate().

◆ GetWeapon()

WsfDirectedEnergyWeapon * WsfHighEnergyLaser::GetWeapon ( ) const

inline

References mWeaponPtr.

Referenced by WsfDefaultHEL::Propagate(), and UpdateEngagementGeometry().

◆ GetWindowStrehl()

virtual double WsfHighEnergyLaser::GetWindowStrehl ( ) const

inlinevirtual

Get the strehl due to window effects (default is 1.0 [no effect]).

◆ Initialize()

bool WsfHighEnergyLaser::Initialize ( WsfDirectedEnergyWeapon * aWeaponPtr )

virtual

References WsfPlatformPart::DebugEnabled(), mDebug, and mWeaponPtr.

◆ IsLasing()

bool WsfHighEnergyLaser::IsLasing ( ) const

inline

Return whether the weapon is currently lasing.

References mIsLasing.

◆ operator=()

WsfHighEnergyLaser & WsfHighEnergyLaser::operator= ( const WsfHighEnergyLaser & )

delete

References WsfHighEnergyLaser().

◆ OutputConfiguration()

virtual void WsfHighEnergyLaser::OutputConfiguration ( ) const

inlinevirtual

◆ ProcessInput()

bool WsfHighEnergyLaser::ProcessInput ( UtInput & aInput )

overridevirtual

Process input from a generic source.

Examine the current input command. If it is NOT one of the commands recognized by this class then it simply returns 'false'. If it is one of the commands recognized by this class then it processes the command and returns 'true'.

Parameters

aInput a reference to a UtInput object.

Returns: 'true' if the command was one recognized by the class or 'false' if not.

Exceptions

UtInput::ExceptionBase (or an object derived from it) if the command was recognized but contains some sort of error.

Note: If a derived class does not recognize the command (i.e.: the return value is false) then it should call the base class ProcessInput method. This chain should continue until either the command is recognized or the top-level base class is encountered.

Reimplemented from WsfDirectedEnergyWeapon::Beam.

References mCalculateIncidence, mDefaultDamageRadius, mTurbulenceModel, WsfDirectedEnergyWeapon::Beam::SetApertureDiameter(), SetBeamQuality(), WsfDirectedEnergyWeapon::Beam::SetInitialPower(), SetJitter(), and WsfDirectedEnergyWeapon::Beam::SetWavelength().

Referenced by WsfDefaultHEL::ProcessInput().

◆ Propagate()

void WsfHighEnergyLaser::Propagate ( double )

overrideprotectedpure virtual

Propagate the beam to the target.

Note: This method's signature may be changed in the future.

Reimplemented from WsfDirectedEnergyWeapon::Beam.

Implemented in WsfDefaultHEL.

Referenced by UpdateLasing().

◆ RequiredDurationEnergy() [1/2]

virtual double WsfHighEnergyLaser::RequiredDurationEnergy	(	double	aEnergy,
		const WsfGeoPoint &	aSourceLocation,
		const WsfGeoPoint &	aTargetLocation )

inlinevirtual

Determine from the given geometry and desired total energy the required duration.

Parameters

aEnergy	The total energy on target.
aSourceLocation	The laser's location.
aTargetLocation	The perceived target location.

Returns: The required duration for lasing, or 0.0 if unsuccessful.

◆ RequiredDurationEnergy() [2/2]

virtual double WsfHighEnergyLaser::RequiredDurationEnergy	(	double	aEnergy,
		int	aTargetIndex,
		const std::string &	aTargetOffset = "" )

inlinevirtual

Determine from the given geometry and desired total energy the required duration.

Parameters

aEnergy	The total energy on target.
aTargetIndex	A target index against which to laser.
aTargetOffset	The intended target offset to

Returns: The required duration for lasing, or 0.0 if unsuccessful.

◆ RequiredDurationFluence() [1/2]

virtual double WsfHighEnergyLaser::RequiredDurationFluence	(	double	aEnergyDensity,
		const WsfGeoPoint &	aSourceLocation,
		const WsfGeoPoint &	aTargetLocation )

inlinevirtual

Determine from the given geometry and desired energy density the required duration.

Parameters

aEnergyDensity	The energy density on target.
aSourceLocation	The laser's location.
aTargetLocation	The perceived target location.

Returns: The required duration for lasing, or 0.0 if unsuccessful.

◆ RequiredDurationFluence() [2/2]

virtual double WsfHighEnergyLaser::RequiredDurationFluence	(	double	aEnergyDensity,
		size_t	aTargetIndex,
		const std::string &	aTargetOffset = "" )

inlinevirtual

Determine from the given geometry and desired energy density the required duration.

Parameters

aEnergyDensity	The energy density on target.
aTargetIndex	A target index against which to laser.
aTargetOffset	The intended target offset to

Returns: The required duration for lasing, or 0.0 if unsuccessful.

◆ SetAeroStrehl()

virtual void WsfHighEnergyLaser::SetAeroStrehl ( double aAeroStrehl )

inlinevirtual

Set the areo strehl (strehl from aerooptics; should be between 0 and 1).

◆ SetAtmosphericStructure()

virtual void WsfHighEnergyLaser::SetAtmosphericStructure ( const std::string & aAtmosphericStructure )

inlinevirtual

References mTurbulenceModel.

◆ SetBeamQuality()

void WsfHighEnergyLaser::SetBeamQuality ( double aBeamQuality )

inline

Set the beam quality wrt a perfect Gaussian beam.

References mBeamQuality.

Referenced by ProcessInput().

◆ SetDamageRadius()

virtual void WsfHighEnergyLaser::SetDamageRadius ( double aDamageRadius )

inlinevirtual

Set the max. radius about which the laser is effective.

Note: This value is usually set in the framework based on values defined in WsfHEL_Lethality.

References mDamageRadius.

◆ SetJitter()

void WsfHighEnergyLaser::SetJitter ( double aJitter )

inline

Set the expected value for the jitter of the HEL on target.

References mJitterExpectedValue.

Referenced by ProcessInput().

◆ SetSystemStrehl()

virtual void WsfHighEnergyLaser::SetSystemStrehl ( double aSystemStrehl )

inlinevirtual

Set the total rms system strehl.

◆ SetWindowStrehl()

virtual void WsfHighEnergyLaser::SetWindowStrehl ( double aWindowStrehl )

inlinevirtual

Set the window strehl (should be between 0 and 1).

◆ TargetOccluded()

virtual bool WsfHighEnergyLaser::TargetOccluded ( ) const

inlinevirtual

Return whether the HEL-target interaction results in a target occlusion.

Note: For this result to be valid, either there must be an active engagement (you've called Fire(...), or you first call UpdateTargetGeometry(...).

References mTargetOccluded.

Referenced by UT_DEFINE_SCRIPT_METHOD().

◆ TestLasing() [1/2]

virtual bool WsfHighEnergyLaser::TestLasing	(	double	aDuration,
		const WsfGeoPoint &	aSourceLocation,
		const WsfGeoPoint &	aTargetLocation )

inlinevirtual

Test the laser against a perceived target in a particular location without actually engaging.

Parameters

aDuration	A specific duration to lase.
aSourceLocation	The laser's location.
aTargetLocation	The perceived target location.

Returns: Whether the test was successful.

◆ TestLasing() [2/2]

virtual bool WsfHighEnergyLaser::TestLasing	(	double	aDuration,
		size_t	aTargetIndex,
		const std::string &	aTargetOffset = "" )

inlinevirtual

Test the laser against a specific target without actually engaging.

Parameters

aDuration	A specific duration to lase.
aTargetIndex	A target index against which to laser.
aTargetOffset	The intended target offset to

Returns: Whether the test was successful.

◆ UpdateEngagementGeometry()

bool WsfHighEnergyLaser::UpdateEngagementGeometry	(	double	aSimTime,
		size_t	aTargetIndex,
		const std::string &	aTargetOffset = "",
		bool	aAddJitter = true )

virtual

Set up all engagement geometry in preparation for the laser propagation calculation. This includes weapon and target positioning and optional raycasting to a target offset with specified jitter.

Parameters

aSimTime	the current simulation time.
aTargetIndex	The target index against which the laser will fire.
aTargetOffset	The desired target offset if any (used for raycasting).
aAddJitter	The jitter offset calculated instantaneously (used in raycasting).

Note: This is also used to perform an independent raycasting calculation to determine target occlusion.

Default target geometry update calculation. This should be extended, possibly as a template method, to account for the new geometry meshes.

References cWSF_COMPONENT_INTERSECT_MESH, WsfComponentListT< COMPONENT_TYPE >::FindComponentByRole(), WsfAuxDataEnabled::GetAuxDataConst(), WsfDirectedEnergyWeapon::GetBeam(), WsfComponentList::GetComponent(), WsfPlatform::GetIndex(), WsfSimulation::GetPlatformByIndex(), WsfSimulation::GetRandom(), GetSimulation(), WsfIntersectMesh::GetTargetOffsetName(), WsfIntersectProcessor::GetTargetOffsetName(), GetWeapon(), WsfIntersectMesh::Intersect(), WsfIntersectProcessor::Intersect(), mCalculateIncidence, mIncidenceAngle, mJitterExpectedValue, mTargetOccluded, mTargetOffsetName, mTargetRange, mWeaponPtr, WsfDirectedEnergyWeapon::Beam::SetIncidenceAngle(), WsfIntersectMesh::TargetOffsetExists(), WsfIntersectProcessor::TargetOffsetExists(), and WsfPlatform::Update().

Referenced by UpdateLasing(), and UT_DEFINE_SCRIPT_METHOD().

◆ UpdateLasing()

void WsfHighEnergyLaser::UpdateLasing ( double aSimTime )

Assuming a laser engagement is underway, update the target geometry and Integrate the fluence on target.

References mIsLasing, mLastUpdateTime, mTargetIndex, mTargetOffsetName, Propagate(), and UpdateEngagementGeometry().

Referenced by BeginLasing().

Member Data Documentation

◆ mBeamQuality

double WsfHighEnergyLaser::mBeamQuality

protected

Referenced by SetBeamQuality(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mCalculateIncidence

bool WsfHighEnergyLaser::mCalculateIncidence

protected

Referenced by ProcessInput(), UpdateEngagementGeometry(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mDamageRadius

double WsfHighEnergyLaser::mDamageRadius

protected

Referenced by GetDamageRadius(), SetDamageRadius(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mDebug

bool WsfHighEnergyLaser::mDebug

protected

Referenced by Initialize(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mDefaultDamageRadius

double WsfHighEnergyLaser::mDefaultDamageRadius

protected

Referenced by GetDefaultDamageRadius(), ProcessInput(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mIncidenceAngle

double WsfHighEnergyLaser::mIncidenceAngle

protected

Referenced by GetIncidenceAngle(), UpdateEngagementGeometry(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mIsLasing

bool WsfHighEnergyLaser::mIsLasing

protected

Referenced by BeginLasing(), EndLasing(), IsLasing(), UpdateLasing(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mJitterExpectedValue

double WsfHighEnergyLaser::mJitterExpectedValue

protected

Referenced by GetJitter(), SetJitter(), UpdateEngagementGeometry(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mLastUpdateTime

double WsfHighEnergyLaser::mLastUpdateTime

protected

Referenced by BeginLasing(), UpdateLasing(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mSysInit

bool WsfHighEnergyLaser::mSysInit

protected

The weapon object associated with the HEL.

Referenced by WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mTargetIndex

size_t WsfHighEnergyLaser::mTargetIndex

protected

Referenced by BeginLasing(), EndLasing(), GetTargetIndex(), WsfDefaultHEL::Propagate(), UpdateLasing(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mTargetOccluded

bool WsfHighEnergyLaser::mTargetOccluded

protected

Referenced by WsfDefaultHEL::Propagate(), TargetOccluded(), UpdateEngagementGeometry(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mTargetOffsetName

WsfStringId WsfHighEnergyLaser::mTargetOffsetName

protected

Referenced by BeginLasing(), UpdateEngagementGeometry(), UpdateLasing(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mTargetRange

double WsfHighEnergyLaser::mTargetRange

protected

Referenced by GetTargetRange(), UpdateEngagementGeometry(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mTurbulenceModel

wsf::AtmosphericTurbulence WsfHighEnergyLaser::mTurbulenceModel

protected

Referenced by ProcessInput(), SetAtmosphericStructure(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

◆ mWeaponPtr

WsfDirectedEnergyWeapon* WsfHighEnergyLaser::mWeaponPtr

protected

Referenced by GetSimulation(), GetWeapon(), Initialize(), WsfDefaultHEL::Propagate(), UpdateEngagementGeometry(), WsfHighEnergyLaser(), and WsfHighEnergyLaser().

The documentation for this class was generated from the following files:

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ WsfHighEnergyLaser() [1/2]

◆ WsfHighEnergyLaser() [2/2]

◆ ~WsfHighEnergyLaser()

Member Function Documentation

◆ BeginLasing()

◆ Clone()

◆ EndLasing()

◆ GetAeroStrehl()

◆ GetDamageRadius()

◆ GetDefaultDamageRadius()

◆ GetIncidenceAngle()

◆ GetJitter()

◆ GetSimulation()

◆ GetSystemStrehl()

◆ GetSystemTransmission()

◆ GetTargetIndex()

◆ GetTargetRange()

◆ GetWeapon()

◆ GetWindowStrehl()

◆ Initialize()

◆ IsLasing()

◆ operator=()

◆ OutputConfiguration()

◆ ProcessInput()

◆ Propagate()

◆ RequiredDurationEnergy() [1/2]

◆ RequiredDurationEnergy() [2/2]

◆ RequiredDurationFluence() [1/2]

◆ RequiredDurationFluence() [2/2]

◆ SetAeroStrehl()

◆ SetAtmosphericStructure()

◆ SetBeamQuality()

◆ SetDamageRadius()

◆ SetJitter()

◆ SetSystemStrehl()

◆ SetWindowStrehl()

◆ TargetOccluded()

◆ TestLasing() [1/2]

◆ TestLasing() [2/2]

◆ UpdateEngagementGeometry()

◆ UpdateLasing()

Member Data Documentation

◆ mBeamQuality

◆ mCalculateIncidence

◆ mDamageRadius

◆ mDebug

◆ mDefaultDamageRadius

◆ mIncidenceAngle

◆ mIsLasing

◆ mJitterExpectedValue

◆ mLastUpdateTime

◆ mSysInit

◆ mTargetIndex

◆ mTargetOccluded

◆ mTargetOffsetName

◆ mTargetRange

◆ mTurbulenceModel

◆ mWeaponPtr
