#include <WsfEW_EA.hpp>

Inheritance diagram for WsfEW_EA:

[legend]

Collaboration diagram for WsfEW_EA:

[legend]

Classes
class	EA_Technique
	Special class to handle the EA specific technique implementations as required. More...

Public Member Functions
	WsfEW_EA ()
WsfEW_EA &	operator= (const WsfEW_EA &)=delete
	~WsfEW_EA () override
Public Member Functions inherited from WsfEW_EA_EP
	WsfEW_EA_EP ()
WsfEW_EA_EP &	operator= (const WsfEW_EA_EP &)=delete
	~WsfEW_EA_EP () override=default
bool	HasFrequencyAgilityEffect () const
bool	EffectIsAvailable (WsfStringId aEffectNameId) const
bool	EffectIsAvailable (WsfEW_Types::TechniqueId aTechId, WsfStringId aEffectNameId) const
virtual WsfEW_Effect *	GetEffect (WsfEW_Types::TechniqueId aTechId, unsigned int aIndex) const
virtual WsfEW_Effect *	GetEffect (WsfEW_Types::TechniqueId aTechId, WsfStringId aEffectId) const
virtual const WsfEW_Technique::EffectPtrVec &	GetEffects (WsfEW_Types::TechniqueId aId) const
WsfSimulation *	GetSimulation () const
bool	ProcessInput (UtInput &aInput) override
virtual bool	DebugEnabled () const
	Determines if debugging is enabled.
virtual WsfEM_XmtrRcvr &	GetLinkedXmtrRcvr () const
virtual void	RemoveJammerXmtr (unsigned int aXmtrId)
virtual void	RemoveJammerXmtr (WsfEM_Xmtr *aXmtrPtr)
virtual WsfEW_Technique::EffectPtrVec	GetMitigatingEffects (const WsfEW_Effect *aEA_EffectPtr, WsfEW_Effect::SystemFunction aAffectingSystemFunction, WsfEW_Effect::SystemFunction aAffectedSystemFunction)
bool	TechniquesAreAvailable () const
	Return true if there are techniques available, 0 otherwise.
bool	TechniquesAreInUse () const
	Return true if there are techniques in use, 0 otherwise.
bool	TechniqueIsAvailable (WsfEW_Types::TechniqueId aId) const
bool	TechniqueIsInUse (WsfEW_Types::TechniqueId aId) const
bool	TechniqueIsExternallyControlled (WsfEW_Types::TechniqueId aId) const
const WsfEW_Types::TechniqueIdVec &	GetTechniquesAvailable () const
	Return a list of all the technique Ids that are currently available.
const WsfEW_Types::TechniqueIdVec &	GetTechniquesInUse () const
	Return a list of all the technique Ids that are currently in use.
void	SetTechnique (WsfEW_Types::TechniqueId aTechniqueId, bool aOnOff)
void	ResetTechniquesInUseList ()
virtual bool	CanApplyTechnique (WsfEW_Types::TechniqueId aId, WsfEW_Effect::SystemFunction aSystemFunction) const
virtual WsfEW_Types::TechniqueIdVec *	GetMitigatedTechniques ()
Public Member Functions inherited from WsfObject
	WsfObject ()
	This is the constructor for the WsfObject class.
	~WsfObject () override
	This is the destructor for the WsfObject class.
const char *	GetScriptClassName () const override
const std::string &	GetType () const
WsfStringId	GetTypeId () const
	Get the string ID of the 'type' of the object.
void	SetType (WsfStringId aType)
const std::string &	GetBaseType () const
WsfStringId	GetBaseTypeId () const
const TypeList &	GetTypeList () const
bool	IsA_TypeOf (WsfStringId aType) const
WsfObject &	operator= (const WsfObject &aRhs)
	Assignment operator.
template<typename T>
void	Serialize (T &aBuff)
	For XIO (de)serialization.
const std::string &	GetName () const
WsfStringId	GetNameId () const
void	SetName (WsfStringId aName)

Static Public Member Functions
static WsfEW_EA_EP *	GetElectronicAttack (const WsfEM_Xmtr &aXmtr)
	Convenience method to get the electronic attack object for the specified transmitter.
static void	SetElectronicAttack (WsfEM_Xmtr &aXmtr, WsfEW_EA_EP *aElectronicAttackPtr)
	Convenience method to set the electronic attack object for the specified transmitter.

Technique methods.
typedef std::map< WsfEW_Types::TechniqueId, EA_Technique * >	TechniqueIdToPtrMap
	Map the technique's ID to its location (pointer).
typedef std::map< WsfEW_Types::TechniqueId, EA_Technique * >::iterator	TechniqueIdToPtrMapIter
typedef std::map< WsfEW_Types::TechniqueId, EA_Technique * >::const_iterator	TechniqueIdToPtrMapConstIter
bool	AddTechnique (WsfEW_Technique *aTechniquePtr) override
WsfEW_Technique *	GetTechnique (WsfEW_Types::TechniqueId aTechniqueId) const override
WsfEW_Technique *	GetTechnique (unsigned int aIndex) const override
virtual bool	SelectTechnique (unsigned int aIndex, WsfEW_Effect::SystemFunction aSystemFunction)
virtual bool	SelectTechnique (WsfEW_Types::TechniqueId aId, WsfEW_Effect::SystemFunction aSystemFunction)
virtual bool	DeselectTechnique (unsigned int aIndex, WsfEW_Effect::SystemFunction aSystemFunction)
virtual bool	DeselectTechnique (WsfEW_Types::TechniqueId aId, WsfEW_Effect::SystemFunction aSystemFunction)
bool	SetDeltaGainTechnique (double aSimTime, WsfStringId aTechniqueId, bool aOnOff, bool aDebug, WsfStringId aEffectId, double aJammingDeltaGain, WsfStringId aSystemTypeId, WsfStringId aSystemFunctionId) override
virtual bool	DeselectTechnique (unsigned int aIndex)
virtual bool	DeselectTechnique (WsfEW_Types::TechniqueId aId)
virtual bool	SelectTechnique (unsigned int aIndex)
virtual bool	SelectTechnique (WsfEW_Types::TechniqueId aId)
	WsfEW_EA (const WsfEW_EA &aSrc)

Common infrastructure methods.
WsfEW_EA_EP *	Clone () const override
bool	Initialize (WsfSimulation &aSimulation, WsfEM_XmtrRcvr *aXmtrRcvrPtr) override

Additional Inherited Members
Public Types inherited from WsfObject
typedef std::vector< WsfStringId >	TypeList
	The list of types returned by GetTypeList.
	WsfEW_EA_EP (const WsfEW_EA_EP &aSrc)
bool	PrivateSetTechnique (WsfEW_Types::TechniqueId aTechnique, bool aOnOff)
	WsfObject (const WsfObject &aSrc)
	Copy constructor (for Clone()).
WsfSimulation *	mSimulationPtr
WsfEW_Types::TechniqueIdVec	mTechniques
	A collection/list of all the Techniques by Id.
WsfEW_Types::TechniqueIdVec	mTechniquesInUse
	A collection of all the Techniques currently in use by Id.
bool	mDebug
	Debug flag 'true' if debug is enabled, 'false' otherwise.
WsfEM_XmtrRcvr *	mLinkedXmtrRcvrPtr
	The transmitter/receiver to which this EA/EP is linked to.

Detailed Description

A class which encapsulates data and functionality related to an Electronic Attack.

An instance of this class is aggregated into a weapon whose intent is to defeat an adversary using electromagnetic emissions. The attack may be designed to confuse, disorient, blind, or otherwise deceive an opponents sensors, or overwhelm his ability to process a voluminous amount of mis-information. The attack may include employing one or more preplanned counter-counter-techniques in response to the adversary's recognition of the attack, and a corresponding attempt to nullify it.

Member Typedef Documentation

◆ TechniqueIdToPtrMap

typedef std::map<WsfEW_Types::TechniqueId, EA_Technique*> WsfEW_EA::TechniqueIdToPtrMap

Map the technique's ID to its location (pointer).

◆ TechniqueIdToPtrMapConstIter

typedef std::map<WsfEW_Types::TechniqueId,EA_Technique*>::const_iterator WsfEW_EA::TechniqueIdToPtrMapConstIter

◆ TechniqueIdToPtrMapIter

typedef std::map<WsfEW_Types::TechniqueId,EA_Technique*>::iterator WsfEW_EA::TechniqueIdToPtrMapIter

Constructor & Destructor Documentation

◆ WsfEW_EA() [1/2]

WsfEW_EA::WsfEW_EA ( )

References WsfEW_EA_EP::WsfEW_EA_EP().

Referenced by Clone(), operator=(), and WsfEW_EA().

◆ ~WsfEW_EA()

WsfEW_EA::~WsfEW_EA ( )

override

References WsfEW_EA_EP::mTechniques.

◆ WsfEW_EA() [2/2]

WsfEW_EA::WsfEW_EA ( const WsfEW_EA & aSrc )

protected

References WsfEW_EA(), and WsfEW_EA_EP::WsfEW_EA_EP().

Member Function Documentation

◆ AddTechnique()

bool WsfEW_EA::AddTechnique ( WsfEW_Technique * aTechniquePtr )

overridevirtual

Reimplemented from WsfEW_EA_EP.

References WsfEW_EA_EP::AddTechnique(), and WsfObject::GetNameId().

◆ Clone()

WsfEW_EA_EP * WsfEW_EA::Clone ( ) const

overridevirtual

Clone this object.

Returns: a pointer to the new object.

Implements WsfEW_EA_EP.

References WsfEW_EA(), and WsfEW_EA_EP::WsfEW_EA_EP().

◆ DeselectTechnique() [1/4]

bool WsfEW_EA_EP::DeselectTechnique ( unsigned int aIndex )

virtual

Deselect a technique for use based on technique index

Parameters

aIndex Specifies the index of the technique in the list (0 - size mTechniques-1).

Returns: Returns true if the technique was successfully deselected.

Reimplemented from WsfEW_EA_EP.

◆ DeselectTechnique() [2/4]

bool WsfEW_EA::DeselectTechnique	(	unsigned int	aIndex,
		WsfEW_Effect::SystemFunction	aSystemFunction )

virtual

Deselect a technique for use based on technique index for the specified System Type

Parameters

aIndex	Specifies the index of the technique in the list (0 - size mTechniques-1).
aSystemFunction	Indicates what system type that the effect will be applied to (i.e. Comms, Sensors, etc.).

Returns: Returns true if the technique was successfully deselected.

References WsfEW_EA_EP::mDebug, WsfEW_EA_EP::mTechniques, and WsfEW_EA_EP::PrivateSetTechnique().

◆ DeselectTechnique() [3/4]

bool WsfEW_EA_EP::DeselectTechnique ( WsfEW_Types::TechniqueId aId )

virtual

Deselect a technique for use based on technique Id

Parameters

aId	Specifies the Id of the technique in the list.

Returns: Returns true if the technique was successfully deselected.

Reimplemented from WsfEW_EA_EP.

◆ DeselectTechnique() [4/4]

bool WsfEW_EA::DeselectTechnique	(	WsfEW_Types::TechniqueId	aId,
		WsfEW_Effect::SystemFunction	aSystemFunction )

virtual

Deselect a technique for use based on technique Id for the specified System Type

Parameters

aId	Specifies the Id of the technique in the list.
aSystemFunction	Indicates what system type that the effect will be applied to (i.e. Comms, Sensors, etc.).

Returns: Returns true if the technique was successfully deselected.

References WsfEW_EA_EP::mDebug, and WsfEW_EA_EP::PrivateSetTechnique().

◆ GetElectronicAttack()

WsfEW_EA_EP * WsfEW_EA::GetElectronicAttack ( const WsfEM_Xmtr & aXmtr )

static

Convenience method to get the electronic attack object for the specified transmitter.

References WsfEW_XmtrComponent::Find(), WsfEW_XmtrComponent::GetElectronicAttack(), and WsfEW_EA_EP::WsfEW_EA_EP().

Referenced by WsfRF_Jammer::DeselectEA_Technique(), WsfXIO_WeaponComponent::EM_XmtrInfo_Load(), WsfEW_Effects::Process(), WsfRF_Jammer::SelectEA_Technique(), WsfRF_Jammer::SetEA_DeltaGainTechnique(), WsfRF_Jammer::SetEA_DeltaGainTechnique(), WsfRF_Jammer::StartJamming(), WsfMilDisInterface::UpdateBeamFromXmtr(), WsfEW_SensorComponent::EW_Mode::UpdateFalseTargetInteractors(), WsfRF_Jammer::UpdateJamming(), and UT_DEFINE_SCRIPT_METHOD().

◆ GetTechnique() [1/2]

WsfEW_Technique * WsfEW_EA::GetTechnique ( unsigned int aIndex ) const

overridevirtual

Reimplemented from WsfEW_EA_EP.

References WsfEW_EA_EP::mTechniques.

◆ GetTechnique() [2/2]

WsfEW_Technique * WsfEW_EA::GetTechnique ( WsfEW_Types::TechniqueId aTechniqueId ) const

overridevirtual

Reimplemented from WsfEW_EA_EP.

Referenced by Initialize().

◆ Initialize()

bool WsfEW_EA::Initialize	(	WsfSimulation &	aSimulation,
		WsfEM_XmtrRcvr *	aXmtrRcvrPtr )

overridevirtual

Reimplemented from WsfEW_EA_EP.

References GetTechnique(), WsfEW_EA_EP::Initialize(), WsfEW_EA_EP::mTechniques, WsfEW_Technique::SetEA_EP_Ptr(), and success.

◆ operator=()

WsfEW_EA & WsfEW_EA::operator= ( const WsfEW_EA & )

delete

References WsfEW_EA(), and WsfEW_EA_EP::WsfEW_EA_EP().

◆ SelectTechnique() [1/4]

bool WsfEW_EA_EP::SelectTechnique ( unsigned int aIndex )

virtual

Selects a technique for use based on technique index

Parameters

aIndex Specifies the index of the technique in the list (0 - size mTechniques-1).

Returns: Returns true if the technique was successfully selected.

Reimplemented from WsfEW_EA_EP.

◆ SelectTechnique() [2/4]

bool WsfEW_EA::SelectTechnique	(	unsigned int	aIndex,
		WsfEW_Effect::SystemFunction	aSystemFunction )

virtual

Selects a technique for use based on technique index for the specified System Type

Parameters

aIndex	Specifies the index of the technique in the list (0 - size mTechniques-1).
aSystemFunction	Indicates what system type that the effect will be applied to (i.e. Comms, Sensors, etc.).

Returns: Returns true if the technique was successfully selected.

References WsfEW_EA_EP::mDebug, WsfEW_EA_EP::mTechniques, and WsfEW_EA_EP::PrivateSetTechnique().

◆ SelectTechnique() [3/4]

bool WsfEW_EA_EP::SelectTechnique ( WsfEW_Types::TechniqueId aId )

virtual

Selects a technique for use based on technique Id

Parameters

aId	Specifies the Id of the technique in the list.

Returns: Returns true if the technique was successfully selected.

Reimplemented from WsfEW_EA_EP.

◆ SelectTechnique() [4/4]

bool WsfEW_EA::SelectTechnique	(	WsfEW_Types::TechniqueId	aId,
		WsfEW_Effect::SystemFunction	aSystemFunction )

virtual

Selects a technique for use based on technique Id for the specified System Type

Parameters

aId	Specifies the Id of the technique in the list.
aSystemFunction	Indicates what system type that the effect will be applied to (i.e. Comms, Sensors, etc.).

Returns: Returns true if the technique was successfully selected.

References WsfEW_EA_EP::mDebug, and WsfEW_EA_EP::PrivateSetTechnique().

◆ SetDeltaGainTechnique()

bool WsfEW_EA::SetDeltaGainTechnique	(	double	aSimTime,
		WsfStringId	aTechniqueId,
		bool	aOnOff,
		bool	aDebug,
		WsfStringId	aEffectId,
		double	aJammingDeltaGain,
		WsfStringId	aSystemTypeId,
		WsfStringId	aSystemFunctionId )

overridevirtual

Set a jamming modulation technique on an active spot using the supplied criteria.

Parameters

aSimTime	The current simulation time.
aTechniqueId	The assigned technique Id to set.
aOnOff	The default state of the technique.
aDebug	The debug state 'true' or 'false'.
aEffectId	The assigned effect Id to set.
aJammingDeltaGain	The assigned jamming modulation value.
aSystemTypeId	The assigned System Type Id of the target types this technique be applied to.
aSystemFunctionId	The assigned System Function Id of the target types this technique be applied to.

Returns: The request was successful.

Reimplemented from WsfEW_EA_EP.

References WsfObject::GetNameId(), WsfEW_EA_EP::GetSimulation(), WsfEW_EA::EA_Technique::Initialize(), WsfEW_EA_EP::mDebug, WsfEW_EA_EP::mTechniques, WsfEW_Technique::SetDebug(), WsfEW_Technique::SetDefaultOn(), WsfEW_Technique::SetDeltaGainEffect(), WsfEW_Technique::SetEA_EP_Ptr(), and WsfObject::SetName().

◆ SetElectronicAttack()

void WsfEW_EA::SetElectronicAttack	(	WsfEM_Xmtr &	aXmtr,
		WsfEW_EA_EP *	aElectronicAttackPtr )

static

Convenience method to set the electronic attack object for the specified transmitter.

References WsfEW_XmtrComponent::FindOrCreate(), WsfEW_XmtrComponent::SetElectronicAttack(), and WsfEW_EA_EP::WsfEW_EA_EP().

Referenced by WsfRF_Jammer::StartJamming().

The documentation for this class was generated from the following files:

Classes

Public Member Functions

Static Public Member Functions

Technique methods.

Common infrastructure methods.

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ TechniqueIdToPtrMap

◆ TechniqueIdToPtrMapConstIter

◆ TechniqueIdToPtrMapIter

Constructor & Destructor Documentation

◆ WsfEW_EA() [1/2]

◆ ~WsfEW_EA()

◆ WsfEW_EA() [2/2]

Member Function Documentation

◆ AddTechnique()

◆ Clone()

◆ DeselectTechnique() [1/4]

◆ DeselectTechnique() [2/4]

◆ DeselectTechnique() [3/4]

◆ DeselectTechnique() [4/4]

◆ GetElectronicAttack()

◆ GetTechnique() [1/2]

◆ GetTechnique() [2/2]

◆ Initialize()

◆ operator=()

◆ SelectTechnique() [1/4]

◆ SelectTechnique() [2/4]

◆ SelectTechnique() [3/4]

◆ SelectTechnique() [4/4]

◆ SetDeltaGainTechnique()

◆ SetElectronicAttack()
