#include <P6DofThrustProducerObject.hpp>

Inheritance diagram for P6DofThrustProducerObject:

[legend]

Collaboration diagram for P6DofThrustProducerObject:

[legend]

Classes
struct	ThrustControlInputValueData
struct	ThrustBooleanControlInputData

Public Member Functions
	P6DofThrustProducerObject (P6DofScenario *aScenario)
	~P6DofThrustProducerObject () override
P6DofThrustProducerObject &	operator= (const P6DofThrustProducerObject &other)=delete
virtual bool	ProcessInput (UtInput &aInput)=0
virtual bool	Initialize (int64_t aSimTime_nanosec)=0
void	SetParentPropulsionSystem (P6DofPropulsionSystem *aParent)
virtual void	CalculateThrust (double aDeltaT_sec, double aAlt_ft, double aDynPress_lbsqft, double aStatPress_lbssqft, double aSpeed_fps, double aMach, double aAlpha_rad, double aBeta_rad, P6DofForceAndMomentsObject &aForceAndMoment, double &aFuelBurnRate_pps, double &aFuelBurned_lbs)=0
virtual void	UpdateThrust (double aDeltaT_sec, double aAlt_ft, double aDynPress_lbsqft, double aStatPress_lbssqft, double aSpeed_fps, double aMach, double aAlpha_rad, double aBeta_rad, P6DofForceAndMomentsObject &aForceAndMoment, double &aFuelBurnRate_pps, double &aFuelBurned_lbs)=0
virtual std::string	GetClassType ()=0
double	GetThrust_lbs () const
double	GetForwardThrust_lbs () const
void	SetThrustReferenceOffsetAttitude (const UtVec3dX &aReferenceLocation_ft, UtVec3dX &aThrustYPR_rad)
void	SetThrustVectoringEnabled (bool aThrustVectoringEnabled)
bool	ThrustVectoringEnabled () const
void	SetThrustVectoringYaw_deg (double aThrustVectoringYaw_deg)
void	SetThrustVectoringPitch_deg (double aThrustVectoringPitch_deg)
double	GetThrustVectoringYaw_deg () const
double	GetThrustVectoringPitch_deg () const
void	SetThrustReverserEnabled (bool aThrustReverserEnabled)
bool	ThrustReverserEnabled () const
void	SetThrustReverserSetting (double aThrustReverserSetting)
double	GetThrustReverserSetting () const
void	GetThrustLocation (UtVec3dX &aThrustLocation_ft) const
void	GetThrustInstalledAnglesYPR (UtVec3dX &aThrustYPR_rad) const
void	GetCurrentThrustVectorDirection (UtVec3dX &aDirection) const
void	CalcCurrentThrustVectors ()
const P6DofForceAndMomentsObject &	GetThrustForceAndAndMoment () const
virtual double	GetFuelBurnRate_pph () const =0
virtual double	GetMaximumPotentialThrust_lbs (double aAlt_ft, double aDynPress_lbsqft, double aStatPress_lbssqft, double aSpeed_fps, double aMach, double aAlpha_rad, double aBeta_rad)=0
virtual double	GetMinimumPotentialThrust_lbs (double aAlt_ft, double aDynPress_lbsqft, double aStatPress_lbssqft, double aSpeed_fps, double aMach, double aAlpha_rad, double aBeta_rad)=0
P6DofMassProperties *	GetMassProperties () const
virtual void	CalculateCurrentMassProperties ()=0
virtual void	SetThrottlePosition (double aThrottleLeverPosition)=0
virtual double	GetThrottlePosition () const =0
virtual void	Ignite (int64_t aIgniteTimeInFrame_nanosec)=0
virtual void	Shutdown (int64_t aTerminateTime_nanosec=0)=0
virtual bool	AfterburnerIsPresent () const
bool	EngineOperating () const
virtual bool	MayHaveEngineOperating () const
bool	EngineSmoking () const
virtual bool	MayProduceEngineSmoke () const
bool	AfterburnerOn () const
bool	Contrailing () const
virtual bool	MayContrail () const
bool	ProducingSmokeTrail () const
virtual bool	MayProduceSmokeTrail () const
void	MakeEngineSmoke (bool aSmoking)
virtual void	SetControlInputHandles (const P6DofFlightControlSystem *aFlightControls)=0
virtual void	SetControlInputValues (const P6DofFlightControlSystem *aFlightControls)=0
Public Member Functions inherited from P6DofObject
	P6DofObject (P6DofScenario *aScenario)
virtual	~P6DofObject ()=default
P6DofObject *	Clone () const
P6DofScenario *	GetScenario () const
std::string	GetName () const
void	SetName (const std::string &aName)
P6DofVehicle *	GetParentVehicle () const
virtual void	SetParentVehicle (P6DofVehicle *aParentVehicle)

Static Public Member Functions
static void	SetControlInputHandle (const P6DofFlightControlSystem aFlightControls, ThrustControlInputValueData aControlInput)
static void	SetControlInputValue (const P6DofFlightControlSystem aFlightControls, ThrustControlInputValueData aControlInput)

Protected Member Functions
	P6DofThrustProducerObject (const P6DofThrustProducerObject &aSrc)
void	DeriveFrom (const P6DofThrustProducerObject *aSrc)
void	SetMassProperties (P6DofMassProperties *aMassProperties)
UtVec3dX	CalcThrustVectorFromThrust (double aThrust_lbs)
void	CalcThrustProducerFM (double aThrustMagnitude_lbs, P6DofForceAndMomentsObject &aForceAndMoment)
Protected Member Functions inherited from P6DofObject
	P6DofObject (const P6DofObject &aSrc)=default
P6DofObject &	operator= (const P6DofObject &other)=default

Protected Attributes
P6DofPropulsionSystem *	mParentPropulsionSystemPtr
std::string	mTypeOfThrustProducer
UtVec3dX	mNominalThrustVectorDirection
UtVec3dX	mCurrentThrustVectorDirection
UtVec3dX	mReferenceLocation_ft
UtVec3dX	mThrustLocation_ft
P6DofForceAndMomentsObject	mCurrentThrustFM_lbs_ftlbs
UtVec3dX	mThrustInstalledAnglesYPR_rad
double	mThrustOffset_ft
bool	mThrustVectoringEnabled
double	mThrustVectorYaw_rad
double	mThrustVectorPitch_rad
bool	mThrustReverserEnabled
double	mThrustReverserSetting
bool	mShutdownInProgress
int64_t	mShutdownFraction_nanosec
int64_t	mIgniteTimeInFrame_nanosec
bool	mInOpRefAreaValid
double	mInOpRefArea_ft2
P6DofMassProperties *	mMassPropertiesPtr
double	mCurrentThrustFactor
bool	mAfterburnerPresent
bool	mEngineOperating
bool	mEngineSmoking
bool	mAfterburnerOn
bool	mContrailing
bool	mProducingSmokeTrail
bool	mEngineDamageSmokeActivated
Protected Attributes inherited from P6DofObject
P6DofScenario *	mScenario
P6DofVehicle *	mParentVehicle
std::string	mObjName

Constructor & Destructor Documentation

◆ P6DofThrustProducerObject() [1/2]

P6DofThrustProducerObject::P6DofThrustProducerObject ( P6DofScenario * aScenario )

explicit

References mAfterburnerOn, mAfterburnerPresent, mContrailing, mCurrentThrustFactor, mCurrentThrustFM_lbs_ftlbs, mCurrentThrustVectorDirection, mEngineDamageSmokeActivated, mEngineOperating, mEngineSmoking, mIgniteTimeInFrame_nanosec, mInOpRefArea_ft2, mInOpRefAreaValid, mMassPropertiesPtr, mNominalThrustVectorDirection, mParentPropulsionSystemPtr, mProducingSmokeTrail, mReferenceLocation_ft, mShutdownFraction_nanosec, mShutdownInProgress, mThrustInstalledAnglesYPR_rad, mThrustLocation_ft, mThrustOffset_ft, mThrustReverserEnabled, mThrustReverserSetting, mThrustVectoringEnabled, mThrustVectorPitch_rad, mThrustVectorYaw_rad, mTypeOfThrustProducer, and P6DofObject::P6DofObject().

Referenced by DeriveFrom(), operator=(), P6DofJetEngineObject::P6DofJetEngineObject(), P6DofJetEngineObject::P6DofJetEngineObject(), P6DofRamjetEngineObject::P6DofRamjetEngineObject(), P6DofRamjetEngineObject::P6DofRamjetEngineObject(), P6DofRocketLiquidPropellantObject::P6DofRocketLiquidPropellantObject(), P6DofRocketLiquidPropellantObject::P6DofRocketLiquidPropellantObject(), P6DofRocketSolidPropellantObject::P6DofRocketSolidPropellantObject(), P6DofRocketSolidPropellantObject::P6DofRocketSolidPropellantObject(), P6DofThrustProducerObject(), and SetControlInputValues().

◆ ~P6DofThrustProducerObject()

P6DofThrustProducerObject::~P6DofThrustProducerObject ( )

override

References mMassPropertiesPtr.

◆ P6DofThrustProducerObject() [2/2]

P6DofThrustProducerObject::P6DofThrustProducerObject ( const P6DofThrustProducerObject & aSrc )

protected

Member Function Documentation

◆ AfterburnerIsPresent()

virtual bool P6DofThrustProducerObject::AfterburnerIsPresent ( ) const

inlinevirtual

References mAfterburnerPresent.

Referenced by WsfP6DOF_MoverTestObject::FuelBurnAtRequiredThrust(), P6DofVehicle::HasAfterburner(), P6DofJetEngineObject::Ignite(), and WsfP6DOF_MoverTestObject::ThrottleSettingToProduceThrust().

◆ AfterburnerOn()

bool P6DofThrustProducerObject::AfterburnerOn ( ) const

inline

References mAfterburnerOn.

Referenced by WsfP6DOF_Mover::GetEngineAfterburnerOn().

◆ CalcCurrentThrustVectors()

void P6DofThrustProducerObject::CalcCurrentThrustVectors ( )

References mCurrentThrustFactor, mCurrentThrustVectorDirection, mNominalThrustVectorDirection, mThrustInstalledAnglesYPR_rad, mThrustReverserEnabled, mThrustReverserSetting, mThrustVectoringEnabled, mThrustVectorPitch_rad, and mThrustVectorYaw_rad.

Referenced by CalcThrustProducerFM().

◆ CalcThrustProducerFM()

void P6DofThrustProducerObject::CalcThrustProducerFM	(	double	aThrustMagnitude_lbs,
		P6DofForceAndMomentsObject &	aForceAndMoment )

protected

References P6DofForceAndMomentsObject::AddForceAtReferencePoint(), CalcCurrentThrustVectors(), CalcThrustVectorFromThrust(), P6DofForceAndMomentsObject::ClearForcesAndMoments(), mCurrentThrustFactor, P6DofForceAndMomentsObject::MoveRefPoint_ft(), and mThrustLocation_ft.

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), and P6DofRocketSolidPropellantObject::CalculateThrust().

◆ CalcThrustVectorFromThrust()

UtVec3dX P6DofThrustProducerObject::CalcThrustVectorFromThrust ( double aThrust_lbs )

protected

References mCurrentThrustVectorDirection.

Referenced by CalcThrustProducerFM(), and P6DofRocketSolidPropellantObject::CalculateThrust().

◆ CalculateCurrentMassProperties()

virtual void P6DofThrustProducerObject::CalculateCurrentMassProperties ( )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

◆ CalculateThrust()

virtual void P6DofThrustProducerObject::CalculateThrust	(	double	aDeltaT_sec,
		double	aAlt_ft,
		double	aDynPress_lbsqft,
		double	aStatPress_lbssqft,
		double	aSpeed_fps,
		double	aMach,
		double	aAlpha_rad,
		double	aBeta_rad,
		P6DofForceAndMomentsObject &	aForceAndMoment,
		double &	aFuelBurnRate_pps,
		double &	aFuelBurned_lbs )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

Referenced by WsfP6DOF_MoverTestObject::FuelBurnAtRequiredThrust(), WsfP6DOF_MoverTestObject::FuelBurnAtThrottleSetting(), WsfP6DOF_MoverTestObject::ThrottleSettingToProduceThrust(), and WsfP6DOF_MoverTestObject::ThrustAtThrottleSetting().

◆ Contrailing()

bool P6DofThrustProducerObject::Contrailing ( ) const

inline

References mContrailing.

◆ DeriveFrom()

void P6DofThrustProducerObject::DeriveFrom ( const P6DofThrustProducerObject * aSrc )

protected

References mTypeOfThrustProducer, and P6DofThrustProducerObject().

Referenced by P6DofJetEngineObject::DeriveFrom(), P6DofRamjetEngineObject::DeriveFrom(), P6DofRocketLiquidPropellantObject::DeriveFrom(), P6DofRocketSolidPropellantObject::DeriveFrom(), and SetControlInputValues().

◆ EngineOperating()

bool P6DofThrustProducerObject::EngineOperating ( ) const

inline

References mEngineOperating.

◆ EngineSmoking()

bool P6DofThrustProducerObject::EngineSmoking ( ) const

inline

References mEngineSmoking.

◆ GetClassType()

virtual std::string P6DofThrustProducerObject::GetClassType ( )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

References GetForwardThrust_lbs(), GetThrust_lbs(), and SetThrustReferenceOffsetAttitude().

◆ GetCurrentThrustVectorDirection()

void P6DofThrustProducerObject::GetCurrentThrustVectorDirection ( UtVec3dX & aDirection ) const

References mCurrentThrustVectorDirection.

◆ GetForwardThrust_lbs()

double P6DofThrustProducerObject::GetForwardThrust_lbs ( ) const

References mCurrentThrustFM_lbs_ftlbs.

Referenced by GetClassType(), and WsfP6DOF_Mover::GetEngineThrust().

◆ GetFuelBurnRate_pph()

virtual double P6DofThrustProducerObject::GetFuelBurnRate_pph ( ) const

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

Referenced by WsfP6DOF_Mover::GetEngineFuelFlowRate().

◆ GetMassProperties()

P6DofMassProperties * P6DofThrustProducerObject::GetMassProperties ( ) const

inline

References mMassPropertiesPtr.

◆ GetMaximumPotentialThrust_lbs()

virtual double P6DofThrustProducerObject::GetMaximumPotentialThrust_lbs	(	double	aAlt_ft,
		double	aDynPress_lbsqft,
		double	aStatPress_lbssqft,
		double	aSpeed_fps,
		double	aMach,
		double	aAlpha_rad,
		double	aBeta_rad )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

◆ GetMinimumPotentialThrust_lbs()

virtual double P6DofThrustProducerObject::GetMinimumPotentialThrust_lbs	(	double	aAlt_ft,
		double	aDynPress_lbsqft,
		double	aStatPress_lbssqft,
		double	aSpeed_fps,
		double	aMach,
		double	aAlpha_rad,
		double	aBeta_rad )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

◆ GetThrottlePosition()

virtual double P6DofThrustProducerObject::GetThrottlePosition ( ) const

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

◆ GetThrust_lbs()

double P6DofThrustProducerObject::GetThrust_lbs ( ) const

References mCurrentThrustFM_lbs_ftlbs.

Referenced by GetClassType().

◆ GetThrustForceAndAndMoment()

const P6DofForceAndMomentsObject & P6DofThrustProducerObject::GetThrustForceAndAndMoment ( ) const

References mCurrentThrustFM_lbs_ftlbs.

◆ GetThrustInstalledAnglesYPR()

void P6DofThrustProducerObject::GetThrustInstalledAnglesYPR ( UtVec3dX & aThrustYPR_rad ) const

References mThrustInstalledAnglesYPR_rad.

◆ GetThrustLocation()

void P6DofThrustProducerObject::GetThrustLocation ( UtVec3dX & aThrustLocation_ft ) const

References mThrustLocation_ft.

◆ GetThrustReverserSetting()

double P6DofThrustProducerObject::GetThrustReverserSetting ( ) const

inline

References mThrustReverserSetting.

◆ GetThrustVectoringPitch_deg()

double P6DofThrustProducerObject::GetThrustVectoringPitch_deg ( ) const

References mThrustVectorPitch_rad.

◆ GetThrustVectoringYaw_deg()

double P6DofThrustProducerObject::GetThrustVectoringYaw_deg ( ) const

References mThrustVectorYaw_rad.

◆ Ignite()

virtual void P6DofThrustProducerObject::Ignite ( int64_t aIgniteTimeInFrame_nanosec )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

Referenced by P6DofSequencer::TestForActivation().

◆ Initialize()

virtual bool P6DofThrustProducerObject::Initialize ( int64_t aSimTime_nanosec )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

References SetParentPropulsionSystem().

◆ MakeEngineSmoke()

void P6DofThrustProducerObject::MakeEngineSmoke ( bool aSmoking )

References mEngineDamageSmokeActivated.

Referenced by P6DofPropulsionSystem::MakeAnEngineSmoke().

◆ MayContrail()

virtual bool P6DofThrustProducerObject::MayContrail ( ) const

inlinevirtual

◆ MayHaveEngineOperating()

virtual bool P6DofThrustProducerObject::MayHaveEngineOperating ( ) const

inlinevirtual

◆ MayProduceEngineSmoke()

virtual bool P6DofThrustProducerObject::MayProduceEngineSmoke ( ) const

inlinevirtual

◆ MayProduceSmokeTrail()

virtual bool P6DofThrustProducerObject::MayProduceSmokeTrail ( ) const

inlinevirtual

Reimplemented in P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

◆ operator=()

P6DofThrustProducerObject & P6DofThrustProducerObject::operator= ( const P6DofThrustProducerObject & other )

delete

References P6DofThrustProducerObject().

◆ ProcessInput()

virtual bool P6DofThrustProducerObject::ProcessInput ( UtInput & aInput )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

◆ ProducingSmokeTrail()

bool P6DofThrustProducerObject::ProducingSmokeTrail ( ) const

inline

References mProducingSmokeTrail.

◆ SetControlInputHandle()

void P6DofThrustProducerObject::SetControlInputHandle	(	const P6DofFlightControlSystem *	aFlightControls,
		ThrustControlInputValueData *	aControlInput )

static

References P6DofFlightControlSystem::GetControlValueHandle(), P6DofThrustProducerObject::ThrustControlInputValueData::handle, and P6DofThrustProducerObject::ThrustControlInputValueData::name.

Referenced by P6DofJetEngineObject::SetControlInputHandles(), P6DofRamjetEngineObject::SetControlInputHandles(), P6DofRocketLiquidPropellantObject::SetControlInputHandles(), P6DofRocketSolidPropellantObject::SetControlInputHandles(), and SetControlInputValues().

◆ SetControlInputHandles()

virtual void P6DofThrustProducerObject::SetControlInputHandles ( const P6DofFlightControlSystem * aFlightControls )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

◆ SetControlInputValue()

void P6DofThrustProducerObject::SetControlInputValue	(	const P6DofFlightControlSystem *	aFlightControls,
		ThrustControlInputValueData *	aControlInput )

static

References P6DofFlightControlSystem::GetControlValue(), P6DofThrustProducerObject::ThrustControlInputValueData::handle, and P6DofThrustProducerObject::ThrustControlInputValueData::value.

Referenced by P6DofJetEngineObject::SetControlInputValues(), P6DofRamjetEngineObject::SetControlInputValues(), P6DofRocketLiquidPropellantObject::SetControlInputValues(), P6DofRocketSolidPropellantObject::SetControlInputValues(), and SetControlInputValues().

◆ SetControlInputValues()

virtual void P6DofThrustProducerObject::SetControlInputValues ( const P6DofFlightControlSystem * aFlightControls )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

References DeriveFrom(), P6DofThrustProducerObject(), SetControlInputHandle(), and SetControlInputValue().

◆ SetMassProperties()

void P6DofThrustProducerObject::SetMassProperties ( P6DofMassProperties * aMassProperties )

inlineprotected

References mMassPropertiesPtr.

Referenced by P6DofRocketSolidPropellantObject::P6DofRocketSolidPropellantObject().

◆ SetParentPropulsionSystem()

void P6DofThrustProducerObject::SetParentPropulsionSystem ( P6DofPropulsionSystem * aParent )

References mParentPropulsionSystemPtr.

Referenced by P6DofPropulsionSystem::Initialize(), and Initialize().

◆ SetThrottlePosition()

virtual void P6DofThrustProducerObject::SetThrottlePosition ( double aThrottleLeverPosition )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

Referenced by WsfP6DOF_MoverTestObject::FuelBurnAtRequiredThrust(), WsfP6DOF_MoverTestObject::FuelBurnAtThrottleSetting(), WsfP6DOF_MoverTestObject::ThrottleSettingToProduceThrust(), and WsfP6DOF_MoverTestObject::ThrustAtThrottleSetting().

◆ SetThrustReferenceOffsetAttitude()

void P6DofThrustProducerObject::SetThrustReferenceOffsetAttitude	(	const UtVec3dX &	aReferenceLocation_ft,
		UtVec3dX &	aThrustYPR_rad )

References mCurrentThrustVectorDirection, mNominalThrustVectorDirection, mReferenceLocation_ft, mThrustInstalledAnglesYPR_rad, mThrustLocation_ft, and mThrustOffset_ft.

Referenced by GetClassType(), and P6DofPropulsionSystem::Initialize().

◆ SetThrustReverserEnabled()

void P6DofThrustProducerObject::SetThrustReverserEnabled ( bool aThrustReverserEnabled )

inline

References mThrustReverserEnabled.

◆ SetThrustReverserSetting()

void P6DofThrustProducerObject::SetThrustReverserSetting ( double aThrustReverserSetting )

References mThrustReverserSetting.

◆ SetThrustVectoringEnabled()

void P6DofThrustProducerObject::SetThrustVectoringEnabled ( bool aThrustVectoringEnabled )

inline

References mThrustVectoringEnabled.

◆ SetThrustVectoringPitch_deg()

void P6DofThrustProducerObject::SetThrustVectoringPitch_deg ( double aThrustVectoringPitch_deg )

References mThrustVectorPitch_rad.

◆ SetThrustVectoringYaw_deg()

void P6DofThrustProducerObject::SetThrustVectoringYaw_deg ( double aThrustVectoringYaw_deg )

References mThrustVectorYaw_rad.

◆ Shutdown()

virtual void P6DofThrustProducerObject::Shutdown ( int64_t aTerminateTime_nanosec = 0 )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

Referenced by P6DofSequencer::TestForActivation().

◆ ThrustReverserEnabled()

bool P6DofThrustProducerObject::ThrustReverserEnabled ( ) const

inline

References mThrustReverserEnabled.

◆ ThrustVectoringEnabled()

bool P6DofThrustProducerObject::ThrustVectoringEnabled ( ) const

inline

References mThrustVectoringEnabled.

◆ UpdateThrust()

virtual void P6DofThrustProducerObject::UpdateThrust	(	double	aDeltaT_sec,
		double	aAlt_ft,
		double	aDynPress_lbsqft,
		double	aStatPress_lbssqft,
		double	aSpeed_fps,
		double	aMach,
		double	aAlpha_rad,
		double	aBeta_rad,
		P6DofForceAndMomentsObject &	aForceAndMoment,
		double &	aFuelBurnRate_pps,
		double &	aFuelBurned_lbs )

pure virtual

Implemented in P6DofJetEngineObject, P6DofRamjetEngineObject, P6DofRocketLiquidPropellantObject, and P6DofRocketSolidPropellantObject.

Member Data Documentation

◆ mAfterburnerOn

bool P6DofThrustProducerObject::mAfterburnerOn

protected

Referenced by AfterburnerOn(), P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

◆ mAfterburnerPresent

bool P6DofThrustProducerObject::mAfterburnerPresent

protected

Referenced by AfterburnerIsPresent(), P6DofJetEngineObject::CalculateThrust(), P6DofJetEngineObject::DetermineIfAfterburnerIsPresent(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and P6DofJetEngineObject::SetThrottlePosition().

◆ mContrailing

bool P6DofThrustProducerObject::mContrailing

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), Contrailing(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

◆ mCurrentThrustFactor

double P6DofThrustProducerObject::mCurrentThrustFactor

protected

Referenced by CalcCurrentThrustVectors(), CalcThrustProducerFM(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

◆ mCurrentThrustFM_lbs_ftlbs

P6DofForceAndMomentsObject P6DofThrustProducerObject::mCurrentThrustFM_lbs_ftlbs

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), GetForwardThrust_lbs(), GetThrust_lbs(), GetThrustForceAndAndMoment(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

◆ mCurrentThrustVectorDirection

UtVec3dX P6DofThrustProducerObject::mCurrentThrustVectorDirection

protected

Referenced by CalcCurrentThrustVectors(), CalcThrustVectorFromThrust(), GetCurrentThrustVectorDirection(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and SetThrustReferenceOffsetAttitude().

◆ mEngineDamageSmokeActivated

bool P6DofThrustProducerObject::mEngineDamageSmokeActivated

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), MakeEngineSmoke(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

◆ mEngineOperating

bool P6DofThrustProducerObject::mEngineOperating

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), EngineOperating(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

◆ mEngineSmoking

bool P6DofThrustProducerObject::mEngineSmoking

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), EngineSmoking(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

◆ mIgniteTimeInFrame_nanosec

int64_t P6DofThrustProducerObject::mIgniteTimeInFrame_nanosec

protected

Referenced by P6DofRocketSolidPropellantObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::Ignite(), P6DofRocketSolidPropellantObject::Ignite(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

◆ mInOpRefArea_ft2

double P6DofThrustProducerObject::mInOpRefArea_ft2

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), P6DofJetEngineObject::ProcessInput(), P6DofRamjetEngineObject::ProcessInput(), P6DofRocketLiquidPropellantObject::ProcessInput(), and P6DofRocketSolidPropellantObject::ProcessInput().

◆ mInOpRefAreaValid

bool P6DofThrustProducerObject::mInOpRefAreaValid

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), P6DofJetEngineObject::ProcessInput(), P6DofRamjetEngineObject::ProcessInput(), P6DofRocketLiquidPropellantObject::ProcessInput(), and P6DofRocketSolidPropellantObject::ProcessInput().

◆ mMassPropertiesPtr

P6DofMassProperties* P6DofThrustProducerObject::mMassPropertiesPtr

protected

Referenced by P6DofRocketSolidPropellantObject::CalculateCurrentMassProperties(), GetMassProperties(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), SetMassProperties(), and ~P6DofThrustProducerObject().

◆ mNominalThrustVectorDirection

UtVec3dX P6DofThrustProducerObject::mNominalThrustVectorDirection

protected

Referenced by CalcCurrentThrustVectors(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and SetThrustReferenceOffsetAttitude().

◆ mParentPropulsionSystemPtr

P6DofPropulsionSystem* P6DofThrustProducerObject::mParentPropulsionSystemPtr

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), P6DofJetEngineObject::SetFuelTank(), P6DofRamjetEngineObject::SetFuelTank(), P6DofRocketLiquidPropellantObject::SetFuelTank(), and SetParentPropulsionSystem().

◆ mProducingSmokeTrail

bool P6DofThrustProducerObject::mProducingSmokeTrail

protected

Referenced by P6DofJetEngineObject::CalculateThrust(), P6DofRamjetEngineObject::CalculateThrust(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and ProducingSmokeTrail().

◆ mReferenceLocation_ft

UtVec3dX P6DofThrustProducerObject::mReferenceLocation_ft

protected

Referenced by P6DofThrustProducerObject(), P6DofThrustProducerObject(), and SetThrustReferenceOffsetAttitude().

◆ mShutdownFraction_nanosec

int64_t P6DofThrustProducerObject::mShutdownFraction_nanosec

protected

Referenced by P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), P6DofRocketLiquidPropellantObject::Shutdown(), and P6DofRocketSolidPropellantObject::Shutdown().

◆ mShutdownInProgress

bool P6DofThrustProducerObject::mShutdownInProgress

protected

Referenced by P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), P6DofRocketLiquidPropellantObject::Shutdown(), and P6DofRocketSolidPropellantObject::Shutdown().

◆ mThrustInstalledAnglesYPR_rad

UtVec3dX P6DofThrustProducerObject::mThrustInstalledAnglesYPR_rad

protected

Referenced by CalcCurrentThrustVectors(), GetThrustInstalledAnglesYPR(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and SetThrustReferenceOffsetAttitude().

◆ mThrustLocation_ft

UtVec3dX P6DofThrustProducerObject::mThrustLocation_ft

protected

Referenced by CalcThrustProducerFM(), P6DofRocketLiquidPropellantObject::CalculateThrust(), P6DofRocketSolidPropellantObject::CalculateThrust(), GetThrustLocation(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and SetThrustReferenceOffsetAttitude().

◆ mThrustOffset_ft

double P6DofThrustProducerObject::mThrustOffset_ft

protected

Referenced by P6DofThrustProducerObject(), P6DofThrustProducerObject(), P6DofJetEngineObject::ProcessInput(), P6DofRamjetEngineObject::ProcessInput(), P6DofRocketLiquidPropellantObject::ProcessInput(), P6DofRocketSolidPropellantObject::ProcessInput(), and SetThrustReferenceOffsetAttitude().

◆ mThrustReverserEnabled

bool P6DofThrustProducerObject::mThrustReverserEnabled

protected

Referenced by CalcCurrentThrustVectors(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), SetThrustReverserEnabled(), and ThrustReverserEnabled().

◆ mThrustReverserSetting

double P6DofThrustProducerObject::mThrustReverserSetting

protected

Referenced by CalcCurrentThrustVectors(), GetThrustReverserSetting(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and SetThrustReverserSetting().

◆ mThrustVectoringEnabled

bool P6DofThrustProducerObject::mThrustVectoringEnabled

protected

Referenced by CalcCurrentThrustVectors(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), P6DofJetEngineObject::ProcessInput(), P6DofRamjetEngineObject::ProcessInput(), P6DofRocketLiquidPropellantObject::ProcessInput(), P6DofRocketSolidPropellantObject::ProcessInput(), SetThrustVectoringEnabled(), and ThrustVectoringEnabled().

◆ mThrustVectorPitch_rad

double P6DofThrustProducerObject::mThrustVectorPitch_rad

protected

Referenced by CalcCurrentThrustVectors(), GetThrustVectoringPitch_deg(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and SetThrustVectoringPitch_deg().

◆ mThrustVectorYaw_rad

double P6DofThrustProducerObject::mThrustVectorYaw_rad

protected

Referenced by CalcCurrentThrustVectors(), GetThrustVectoringYaw_deg(), P6DofThrustProducerObject(), P6DofThrustProducerObject(), and SetThrustVectoringYaw_deg().

◆ mTypeOfThrustProducer

std::string P6DofThrustProducerObject::mTypeOfThrustProducer

protected

Referenced by DeriveFrom(), P6DofJetEngineObject::P6DofJetEngineObject(), P6DofRamjetEngineObject::P6DofRamjetEngineObject(), P6DofRocketLiquidPropellantObject::P6DofRocketLiquidPropellantObject(), P6DofRocketSolidPropellantObject::P6DofRocketSolidPropellantObject(), P6DofThrustProducerObject(), and P6DofThrustProducerObject().

The documentation for this class was generated from the following files:

Classes

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Constructor & Destructor Documentation

◆ P6DofThrustProducerObject() [1/2]

◆ ~P6DofThrustProducerObject()

◆ P6DofThrustProducerObject() [2/2]

Member Function Documentation

◆ AfterburnerIsPresent()

◆ AfterburnerOn()

◆ CalcCurrentThrustVectors()

◆ CalcThrustProducerFM()

◆ CalcThrustVectorFromThrust()

◆ CalculateCurrentMassProperties()

◆ CalculateThrust()

◆ Contrailing()

◆ DeriveFrom()

◆ EngineOperating()

◆ EngineSmoking()

◆ GetClassType()

◆ GetCurrentThrustVectorDirection()

◆ GetForwardThrust_lbs()

◆ GetFuelBurnRate_pph()

◆ GetMassProperties()

◆ GetMaximumPotentialThrust_lbs()

◆ GetMinimumPotentialThrust_lbs()

◆ GetThrottlePosition()

◆ GetThrust_lbs()

◆ GetThrustForceAndAndMoment()

◆ GetThrustInstalledAnglesYPR()

◆ GetThrustLocation()

◆ GetThrustReverserSetting()

◆ GetThrustVectoringPitch_deg()

◆ GetThrustVectoringYaw_deg()

◆ Ignite()

◆ Initialize()

◆ MakeEngineSmoke()

◆ MayContrail()

◆ MayHaveEngineOperating()

◆ MayProduceEngineSmoke()

◆ MayProduceSmokeTrail()

◆ operator=()

◆ ProcessInput()

◆ ProducingSmokeTrail()

◆ SetControlInputHandle()

◆ SetControlInputHandles()

◆ SetControlInputValue()

◆ SetControlInputValues()

◆ SetMassProperties()

◆ SetParentPropulsionSystem()

◆ SetThrottlePosition()

◆ SetThrustReferenceOffsetAttitude()

◆ SetThrustReverserEnabled()

◆ SetThrustReverserSetting()

◆ SetThrustVectoringEnabled()

◆ SetThrustVectoringPitch_deg()

◆ SetThrustVectoringYaw_deg()

◆ Shutdown()

◆ ThrustReverserEnabled()

◆ ThrustVectoringEnabled()

◆ UpdateThrust()

Member Data Documentation

◆ mAfterburnerOn

◆ mAfterburnerPresent

◆ mContrailing

◆ mCurrentThrustFactor

◆ mCurrentThrustFM_lbs_ftlbs

◆ mCurrentThrustVectorDirection

◆ mEngineDamageSmokeActivated

◆ mEngineOperating

◆ mEngineSmoking

◆ mIgniteTimeInFrame_nanosec

◆ mInOpRefArea_ft2

◆ mInOpRefAreaValid

◆ mMassPropertiesPtr

◆ mNominalThrustVectorDirection

◆ mParentPropulsionSystemPtr

◆ mProducingSmokeTrail
