#include <WsfOrbitalEvent.hpp>

Inheritance diagram for WsfOrbitalEvent:

[legend]

Collaboration diagram for WsfOrbitalEvent:

[legend]

Classes
class	AdvanceMissionEventException

Public Member Functions
	WsfOrbitalEvent (const WsfOrbitalEvent &aSrc)
WsfOrbitalEvent &	operator= (const WsfOrbitalEvent &)=delete
	~WsfOrbitalEvent () override=default
WsfOrbitalEvent *	Clone () const override=0
	Make a copy of this object.
bool	ProcessInput (UtInput &aInput) override
virtual bool	Initialize (const UtCalendar &aEpoch, const wsf::space::OrbitalMissionContext &aContext)
bool	CanVerify () const
	Return whether this event can be verified.
virtual bool	VerifyCondition () const
virtual bool	EvaluatePreconditions (const wsf::space::OrbitalMissionContext &aContext) const
virtual bool	EvaluatePostconditions (const wsf::space::OrbitalMissionContext &aContext) const
virtual bool	ValidateParameterRanges (const std::string &aExecutingPlatformName) const
bool	IsComplete () const
	Return whether the event is complete.
bool	IsCanceled () const
	Return whether the event is canceled.
void	SetCanceled ()
	Mark the event as canceled.
bool	Execute (const UtCalendar &aEpoch, wsf::space::OrbitalMissionContext &aContext)
const char *	GetScriptClassName () const override
bool	IsFinite () const
void	SetFinite (bool aIsFinite)
	Set whether the event is finite.
bool	HasExecuted () const
	Return whether the event has executed at least once (i.e., Execute() has been called).
const wsf::space::OrbitalPropagatorCondition &	GetCondition () const
	Return the condition for event execution (const).
wsf::space::OrbitalPropagatorCondition &	GetCondition ()
	Return the condition for event execution (non-const).
WsfStringId	GetConditionString () const
	Return the condition string for event execution.
void	SetCondition (std::unique_ptr< wsf::space::OrbitalPropagatorCondition > aConditionPtr)
	Set the condition for execution.
const UtCalendar &	GetStartTime () const
	Return the time at which the event will begin executing.
void	SetStartTime (const UtCalendar &aStartTime)
	Set the start time to begin event execution.
const UtCalendar &	GetEvaluationTime () const
	Return the nominal time to execute the event impulsively.
UtTimeValue	GetDuration () const
	Return the full duration of the event. If the event is impulsive, this method returns 0.
void	SetDuration (const UtTimeValue &aDuration)
	Set the full duration of the event. A value of 0 implies and impulsive event; otherwise it is finite.
void	SetOnlyDuration (const UtTimeValue &aDuration)
UtTimeValue	GetUpdateInterval () const
	For finite events, return the interval at which the event is to be re-evaluated.
void	SetUpdateInterval (const UtTimeValue &aUpdateInterval)
	Set the update interval for which the event is to be re-evaluated.
virtual const WsfOrbitalEvent *	GetCurrentMissionEvent () const
virtual WsfOrbitalEvent *	GetCurrentMissionEvent ()
virtual WsfOrbitalEvent *	AdvanceMissionEvent (const UtCalendar &aEpoch, const wsf::space::OrbitalMissionContext &aContext)
virtual bool	IsSequence () const
	Is this MissionEvent a MissionEvent sequence (WsfMissionEventSequence)?
virtual double	GetRequiredDeltaV (const UtOrbitalPropagatorBase &aPropagator) const
	Return the minimum required delta-v needed to complete this event; the default is to return 0.0.
virtual double	GetDeltaV () const
	Get the delta V expended to execute this event; the default is to return 0.0.
virtual bool	GetNextExecutionTime (const UtCalendar &aCurrentTime, const UtOrbitalPropagatorBase &aPropagator, UtCalendar &aNextExecutionTime)
	For finite events, return the next time the event should be executed.
virtual void	Accept (WsfOrbitalEventVisitor *aVisitorPtr)=0
Public Member Functions inherited from WsfUniqueId
	WsfUniqueId ()
	Construtor initializes the unique identifier to 0.
	WsfUniqueId (const WsfUniqueId &)
	Copy constructor initializes the unique identifier to 0.
WsfUniqueId &	operator= (const WsfUniqueId &)
unsigned int	GetUniqueId () const
	Get the unique identifier assigned to this object.
template<typename T>
void	Serialize (T &aBuff)
	For XIO (de)serialization.
Public Member Functions inherited from WsfObject
	WsfObject ()
	This is the constructor for the WsfObject class.
	~WsfObject () override
	This is the destructor for the WsfObject class.
const char *	GetScriptClassName () const override
const std::string &	GetType () const
WsfStringId	GetTypeId () const
	Get the string ID of the 'type' of the object.
void	SetType (WsfStringId aType)
const std::string &	GetBaseType () const
WsfStringId	GetBaseTypeId () const
const TypeList &	GetTypeList () const
bool	IsA_TypeOf (WsfStringId aType) const
WsfObject &	operator= (const WsfObject &aRhs)
	Assignment operator.
template<typename T>
void	Serialize (T &aBuff)
	For XIO (de)serialization.
const std::string &	GetName () const
WsfStringId	GetNameId () const
void	SetName (WsfStringId aName)

Static Public Member Functions
static WsfOrbitalEvent *	Create (const WsfScenario &aScenario, UtInput &aInput, bool aIgnoreSomeExceptions=false)

Protected Member Functions
	WsfOrbitalEvent (const WsfScenario &aScenario)
virtual bool	InitializeVariables (const UtCalendar &aCurrentTime, const UtCalendar &aEvaluationTime, const wsf::space::OrbitalMissionContext &aContext)
virtual bool	InitializeTimes (const UtCalendar &aEpoch, const wsf::space::OrbitalMissionContext &aContext)
virtual bool	ExecuteEvent (const UtCalendar &aCurrentTime, wsf::space::OrbitalMissionContext &aContext)=0
virtual bool	EvaluateCompletion (const UtCalendar &aEpoch, const UtOrbitalPropagatorBase &aPropagator)
Protected Member Functions inherited from WsfUniqueId
void	AssignUniqueId (WsfSimulation *aSimulationPtr)
	WsfObject (const WsfObject &aSrc)
	Copy constructor (for Clone()).

Static Protected Member Functions
static WsfOrbitalEvent *	Create (const WsfScenario &aScenario, WsfStringId aType)

Protected Attributes
ut::CloneablePtr< wsf::space::OrbitalPropagatorCondition >	mCondition {}
bool	mIsFinite
bool	mHasExecuted
bool	mIsComplete
bool	mIsCanceled
bool	mDebug
bool	mCanVerify
UtCalendar	mStartTime
	Can this event be verified without running in a simulation?
UtCalendar	mEvaluationTime
UtTimeValue	mDuration
UtTimeValue	mUpdateInterval
const WsfScenario &	mScenario

Additional Inherited Members
Public Types inherited from WsfObject
typedef std::vector< WsfStringId >	TypeList
	The list of types returned by GetTypeList.

Detailed Description

A Base class for orbital events. Derived classes must define the "ComputeDeltaV" and "Clone" methods. For any events that rely on a Condition (see below) to succeed, the "EvaluatePreconditions" method should be implemented. Likewise, for any post-event criteria that must be evaluated (e.g., orbit not intersecting the Earth), the "EvaluatePostConditions" method should be implemented. Orbital events can either be executed with a mover in the context of a simulation, or they can be executed exclusively with an orbital propagator. In the latter case, the unique id and script accessible base classes are not used.

Constructor & Destructor Documentation

◆ WsfOrbitalEvent() [1/2]

WsfOrbitalEvent::WsfOrbitalEvent ( const WsfOrbitalEvent & aSrc )

References mCanVerify, mCondition, mDebug, mDuration, mEvaluationTime, mHasExecuted, mIsCanceled, mIsComplete, mIsFinite, mScenario, mStartTime, mUpdateInterval, WsfObject::WsfObject(), WsfOrbitalEvent(), and WsfUniqueId::WsfUniqueId().

Referenced by Accept(), AdvanceMissionEvent(), WsfOrbitalMissionSequence::AdvanceMissionEvent(), WsfOrbitalAttitudeChangeEvent::Clone(), Clone(), WsfOrbitalScriptEvent::Clone(), WsfOrbitalStagingEvent::Clone(), Create(), Create(), ExecuteEvent(), GetCurrentMissionEvent(), GetCurrentMissionEvent(), WsfOrbitalMissionSequence::GetCurrentMissionEvent(), WsfOrbitalMissionSequence::GetCurrentMissionEvent(), WsfOrbitalMissionSequence::GetNextMissionEvent(), operator=(), WsfOrbitalScriptEvent::operator=(), WsfOrbitalMissionSequence::ProcessInputWithIgnore(), WsfOrbitalAttitudeChangeEvent::WsfOrbitalAttitudeChangeEvent(), WsfOrbitalAttitudeChangeEvent::WsfOrbitalAttitudeChangeEvent(), WsfOrbitalEvent(), WsfOrbitalManeuver::WsfOrbitalManeuver(), WsfOrbitalMissionSequence::WsfOrbitalMissionSequence(), WsfOrbitalMissionSequence::WsfOrbitalMissionSequence(), WsfOrbitalScriptEvent::WsfOrbitalScriptEvent(), WsfOrbitalScriptEvent::WsfOrbitalScriptEvent(), WsfOrbitalStagingEvent::WsfOrbitalStagingEvent(), WsfOrbitalStagingEvent::WsfOrbitalStagingEvent(), and WsfOrbitalAttitudeChangeEvent::~WsfOrbitalAttitudeChangeEvent().

◆ ~WsfOrbitalEvent()

WsfOrbitalEvent::~WsfOrbitalEvent ( )

overridedefault

◆ WsfOrbitalEvent() [2/2]

WsfOrbitalEvent::WsfOrbitalEvent ( const WsfScenario & aScenario )

explicitprotected

References mCanVerify, mCondition, mDebug, mDuration, mEvaluationTime, mHasExecuted, mIsCanceled, mIsComplete, mIsFinite, mScenario, mStartTime, mUpdateInterval, WsfObject::WsfObject(), and WsfUniqueId::WsfUniqueId().

Member Function Documentation

◆ Accept()

virtual void WsfOrbitalEvent::Accept ( WsfOrbitalEventVisitor * aVisitorPtr )

pure virtual

Implemented in WsfOrbitalAttitudeChangeEvent, WsfOrbitalMissionSequence, WsfOrbitalScriptEvent, and WsfOrbitalStagingEvent.

References InitializeTimes(), InitializeVariables(), and WsfOrbitalEvent().

◆ AdvanceMissionEvent()

WsfOrbitalEvent * WsfOrbitalEvent::AdvanceMissionEvent	(	const UtCalendar &	aEpoch,
		const wsf::space::OrbitalMissionContext &	aContext )

virtual

Return the next MissionEvent object in a sequence (see WsfMissionEventSequence::AdvanceMissionEvent). If this MissionEvent is not a MissionEvent sequence, zero is returned.

Advance to the "next" MissionEvent in the MissionEvent sequence, after the current MissionEvent. The base class' version simply returns nullptr if it has executed, or "this" if not (see WsfOrbitalMissionSequence::AdvanceMissionEvent).

Parameters

aEpoch	The current epoch, to be used as the basis for evaluating the next MissionEvent in the sequence.
aContext	The orbital mission context in which this event is being executed.

Returns: nullptr if this MissionEvent has executed; otherwise, "this".

Reimplemented in WsfOrbitalMissionSequence.

References mHasExecuted, and WsfOrbitalEvent().

Referenced by WsfOrbitalMissionSequence::AdvanceMissionEvent().

◆ CanVerify()

bool WsfOrbitalEvent::CanVerify ( ) const

inline

Return whether this event can be verified.

References mCanVerify.

◆ Clone()

WsfOrbitalEvent * WsfOrbitalEvent::Clone ( ) const

overridepure virtual

Make a copy of this object.

Implements WsfObject.

Implemented in WsfOrbitalAttitudeChangeEvent, WsfOrbitalManeuver, WsfOrbitalMissionSequence, WsfOrbitalScriptEvent, and WsfOrbitalStagingEvent.

References Create(), Initialize(), and WsfOrbitalEvent().

Referenced by Create(), UT_DEFINE_SCRIPT_METHOD(), and UT_DEFINE_SCRIPT_METHOD().

◆ Create() [1/2]

WsfOrbitalEvent * WsfOrbitalEvent::Create	(	const WsfScenario &	aScenario,
		UtInput &	aInput,
		bool	aIgnoreSomeExceptions = false )

static

Factory method to create an orbital event.

Parameters

aScenario	The scenario object that owns the orbital event types factory.
aInput	The input object specifying the orbital event.
aIgnoreSomeExceptions	Indicate if this method should ignore bad value exceptions.

Returns: The newly-created orbital event object.

References Create(), ProcessInput(), and WsfOrbitalEvent().

Referenced by Clone(), Create(), ExecuteEvent(), and WsfOrbitalMissionSequence::ProcessInputWithIgnore().

◆ Create() [2/2]

WsfOrbitalEvent * WsfOrbitalEvent::Create	(	const WsfScenario &	aScenario,
		WsfStringId	aType )

staticprotected

Per-mover factory method to create events by type.

Parameters

aScenario	The current scenario (used to find and clone a prototype event).
aType	The type of event to create.

References Clone(), WsfObjectTypeList< T >::Find(), WsfScenario::GetTypes(), and WsfOrbitalEvent().

◆ EvaluateCompletion()

bool WsfOrbitalEvent::EvaluateCompletion	(	const UtCalendar &	aEpoch,
		const UtOrbitalPropagatorBase &	aPropagator )

protectedvirtual

Evaluate whether an event is marked as complete. If it is complete, mIsComplete is true in Execute(), and the event sequence will progress to the next event.

Note: This is a template method called within Execute(...).

Reimplemented in WsfOrbitalManeuver, and WsfOrbitalScriptEvent.

References mDuration, and mStartTime.

Referenced by WsfOrbitalScriptEvent::EvaluateCompletion(), Execute(), and ExecuteEvent().

◆ EvaluatePostconditions()

bool WsfOrbitalEvent::EvaluatePostconditions ( const wsf::space::OrbitalMissionContext & aContext ) const

virtual

As part of event verification, evaluate any required postconditions associated with the event. These checks involve making sure that this is an expected post-event orbit; for instance, there is no intersection with the earth and it is not hyperbolic.

Parameters

aContext The orbital mission context in which this event is executing.

Returns: True if the postcondititions are met, false otherwise.

Reimplemented in WsfOrbitalManeuver.

◆ EvaluatePreconditions()

bool WsfOrbitalEvent::EvaluatePreconditions ( const wsf::space::OrbitalMissionContext & aContext ) const

virtual

As part of event verification, evaluate any preconditions associated with the event. Usually this involves making sure that the provided WsfOrbitalEvent::Condition is correct.

Parameters

aContext The orbital mission context in which this event is executing.

Returns: True if the preconditions are met, false otherwise.

Reimplemented in WsfOrbitalManeuver.

◆ Execute()

bool WsfOrbitalEvent::Execute	(	const UtCalendar &	aEpoch,
		wsf::space::OrbitalMissionContext &	aContext )

Direct the space mover associated with this MissionEvent to execute the MissionEvent. The space mover may or may not be successful in actually executing the MissionEvent due to delta-V limitations. In the case of finite MissionEvents, this method is called multiple times at the given update interval.

References wsf::space::OrbitalMissionContext::CompleteMissionEvent(), EvaluateCompletion(), ExecuteEvent(), wsf::space::OrbitalMissionContext::GetPropagator(), wsf::space::OrbitalMissionContext::InitiateMissionEvent(), IsComplete(), mHasExecuted, mIsComplete, mStartTime, and wsf::space::OrbitalMissionContext::UpdateMissionEvent().

◆ ExecuteEvent()

virtual bool WsfOrbitalEvent::ExecuteEvent	(	const UtCalendar &	aCurrentTime,
		wsf::space::OrbitalMissionContext &	aContext )

protectedpure virtual

Perform any necessary event processing. For example, in the case of orbital maneuvers, the actual Maneuver(...) method is called and delta-V computations are performed.

Parameters

aCurrentTime	The current time to be used in the event execution.
aContext	The orbital mission context in which this event is executing.

Note: This is a template method called from within Execute(...).

Implemented in WsfOrbitalAttitudeChangeEvent, WsfOrbitalManeuver, WsfOrbitalScriptEvent, and WsfOrbitalStagingEvent.

References Create(), EvaluateCompletion(), and WsfOrbitalEvent().

Referenced by Execute().

◆ GetCondition() [1/2]

wsf::space::OrbitalPropagatorCondition & WsfOrbitalEvent::GetCondition ( )

inline

Return the condition for event execution (non-const).

References mCondition.

◆ GetCondition() [2/2]

const wsf::space::OrbitalPropagatorCondition & WsfOrbitalEvent::GetCondition ( ) const

inline

Return the condition for event execution (const).

References mCondition.

Referenced by WsfOrbitalScriptEvent::GetNextExecutionTime(), WsfOrbitalManeuver::InitializeTimes(), wsf::event::utils::PrintOrbitalManeuverData(), and wsf::event::utilsCSV::PrintOrbitalManeuverData().

◆ GetConditionString()

WsfStringId WsfOrbitalEvent::GetConditionString ( ) const

inline

Return the condition string for event execution.

References mCondition.

Referenced by wsf::event::utils::PrintOrbitalManeuverData(), and wsf::event::utilsCSV::PrintOrbitalManeuverData().

◆ GetCurrentMissionEvent() [1/2]

virtual WsfOrbitalEvent * WsfOrbitalEvent::GetCurrentMissionEvent ( )

inlinevirtual

Return the current MissionEvent object (see WsfOrbitalMissionSequence::GetCurrentMissionEvent). If this MissionEvent is not a MissionEvent sequence, "this" is returned.

Reimplemented in WsfOrbitalMissionSequence.

References WsfOrbitalEvent().

◆ GetCurrentMissionEvent() [2/2]

virtual const WsfOrbitalEvent * WsfOrbitalEvent::GetCurrentMissionEvent ( ) const

inlinevirtual

Return the current event object (see WsfOrbitalMissionSequence::GetCurrentEvent). If this event is not a event sequence, "this" is returned.

Reimplemented in WsfOrbitalMissionSequence.

References WsfOrbitalEvent().

Referenced by WsfOrbitalMissionSequence::GetCurrentMissionEvent(), WsfOrbitalMissionSequence::GetCurrentMissionEvent(), WsfSpaceMoverBase::GetCurrentMissionEvent(), wsf::space::OrbitalMissionSimulationContext::Initialize(), UT_DEFINE_SCRIPT_METHOD(), and UT_DEFINE_SCRIPT_METHOD().

◆ GetDeltaV()

virtual double WsfOrbitalEvent::GetDeltaV ( ) const

inlinevirtual

Get the delta V expended to execute this event; the default is to return 0.0.

Reimplemented in WsfOrbitalManeuver, and WsfOrbitalMissionSequence.

◆ GetDuration()

UtTimeValue WsfOrbitalEvent::GetDuration ( ) const

inline

Return the full duration of the event. If the event is impulsive, this method returns 0.

References mDuration.

Referenced by WsfOrbitalManeuvering::GetManeuverDuration(), wsf::event::utils::PrintOrbitalManeuverData(), and wsf::event::utilsCSV::PrintOrbitalManeuverData().

◆ GetEvaluationTime()

const UtCalendar & WsfOrbitalEvent::GetEvaluationTime ( ) const

inline

Return the nominal time to execute the event impulsively.

References mEvaluationTime.

◆ GetNextExecutionTime()

bool WsfOrbitalEvent::GetNextExecutionTime	(	const UtCalendar &	aCurrentTime,
		const UtOrbitalPropagatorBase &	aPropagator,
		UtCalendar &	aNextExecutionTime )

virtual

For finite events, return the next time the event should be executed.

Reimplemented in WsfOrbitalScriptEvent.

References GetUpdateInterval(), and IsFinite().

Referenced by WsfOrbitalScriptEvent::GetNextExecutionTime().

◆ GetRequiredDeltaV()

virtual double WsfOrbitalEvent::GetRequiredDeltaV ( const UtOrbitalPropagatorBase & aPropagator ) const

inlinevirtual

Return the minimum required delta-v needed to complete this event; the default is to return 0.0.

Reimplemented in WsfOrbitalManeuver, and WsfOrbitalMissionSequence.

◆ GetScriptClassName()

const char * WsfOrbitalEvent::GetScriptClassName ( ) const

inlineoverride

◆ GetStartTime()

const UtCalendar & WsfOrbitalEvent::GetStartTime ( ) const

inline

Return the time at which the event will begin executing.

References mStartTime.

Referenced by WsfOrbitalManeuvering::GetManeuverDuration(), WsfOrbitalManeuvering::Maneuver(), wsf::space::OrbitalMissionSimulationContext::Schedule(), and wsf::space::OrbitalMissionVerificationContext::VerifyMission().

◆ GetUpdateInterval()

UtTimeValue WsfOrbitalEvent::GetUpdateInterval ( ) const

inline

For finite events, return the interval at which the event is to be re-evaluated.

References mUpdateInterval.

Referenced by GetNextExecutionTime().

◆ HasExecuted()

bool WsfOrbitalEvent::HasExecuted ( ) const

inline

Return whether the event has executed at least once (i.e., Execute() has been called).

References mHasExecuted.

Referenced by WsfOrbitalManeuvering::Maneuver().

◆ Initialize()

bool WsfOrbitalEvent::Initialize	(	const UtCalendar &	aEpoch,
		const wsf::space::OrbitalMissionContext &	aContext )

virtual

Initialize this MissionEvent in preparation to execute it.

Parameters

aEpoch	The current epoch, to be used as the basis for evaluating the next mission event in the sequence.
aContext	The orbital mission context in which this event is executing.

Reimplemented in WsfOrbitalAttitudeChangeEvent, WsfOrbitalMissionSequence, and WsfOrbitalScriptEvent.

References WsfUniqueId::AssignUniqueId(), wsf::space::OrbitalMissionContext::GetSimulation(), InitializeTimes(), mCondition, ok, and VerifyCondition().

Referenced by Clone(), WsfOrbitalAttitudeChangeEvent::Initialize(), and WsfOrbitalScriptEvent::Initialize().

◆ InitializeTimes()

bool WsfOrbitalEvent::InitializeTimes	(	const UtCalendar &	aEpoch,
		const wsf::space::OrbitalMissionContext &	aContext )

protectedvirtual

Initialize the start and evaluation times for the event. In the case of finite maneuvers set the start time according to a patched conic approximation.

Note: For finite maneuvers the start time can be before the epoch; in that case we advance the maneuver one or more orbits and print a warning.

Reimplemented in WsfOrbitalManeuver.

References wsf::space::OrbitalMissionContext::GetPropagator(), InitializeVariables(), mCondition, mEvaluationTime, mStartTime, and ok.

Referenced by Accept(), and Initialize().

◆ InitializeVariables()

bool WsfOrbitalEvent::InitializeVariables	(	const UtCalendar &	aCurrentTime,
		const UtCalendar &	aEvaluationTime,
		const wsf::space::OrbitalMissionContext &	aContext )

protectedvirtual

Called during InitializeTimes(), this method should be overridden to ensure proper initialization of any variables used in ComputeDeltaV. Default is to do nothing.

Parameters

aCurrentTime	The current time.
aEvaluationTime	The evaluation time of the event.
aContext	The orbital mission context in which this event is being executed.

Returns: True if initialization was successful; false otherwise.

Referenced by Accept(), InitializeTimes(), and WsfOrbitalManeuver::InitializeTimes().

◆ IsCanceled()

bool WsfOrbitalEvent::IsCanceled ( ) const

inline

Return whether the event is canceled.

References mIsCanceled.

◆ IsComplete()

bool WsfOrbitalEvent::IsComplete ( ) const

inline

Return whether the event is complete.

References mIsComplete.

Referenced by Execute(), WsfOrbitalMissionSequence::GetCurrentMissionEvent(), and WsfOrbitalMissionSequence::GetCurrentMissionEvent().

◆ IsFinite()

bool WsfOrbitalEvent::IsFinite ( ) const

inline

Is the event finite?

Returns: True if finite; false if impulsive.

References mIsFinite.

Referenced by GetNextExecutionTime(), WsfOrbitalScriptEvent::GetNextExecutionTime(), and WsfOrbitalManeuvering::Maneuver().

◆ IsSequence()

virtual bool WsfOrbitalEvent::IsSequence ( ) const

inlinevirtual

Is this MissionEvent a MissionEvent sequence (WsfMissionEventSequence)?

Reimplemented in WsfOrbitalMissionSequence.

◆ operator=()

WsfOrbitalEvent & WsfOrbitalEvent::operator= ( const WsfOrbitalEvent & )

delete

References WsfOrbitalEvent().

◆ ProcessInput()

bool WsfOrbitalEvent::ProcessInput ( UtInput & aInput )

overridevirtual

Process input from a generic source.

Examine the current input command. If it is NOT one of the commands recognized by this class then it simply returns 'false'. If it is one of the commands recognized by this class then it processes the command and returns 'true'.

Parameters

aInput a reference to a UtInput object.

Returns: 'true' if the command was one recognized by the class or 'false' if not.

Exceptions

UtInput::ExceptionBase (or an object derived from it) if the command was recognized but contains some sort of error.

Note: If a derived class does not recognize the command (i.e.: the return value is false) then it should call the base class ProcessInput method. This chain should continue until either the command is recognized or the top-level base class is encountered.

Reimplemented from WsfObject.

Reimplemented in WsfOrbitalMissionSequence, and WsfOrbitalScriptEvent.

References wsf::space::OrbitalPropagatorConditionTypes::Get(), mCondition, mDebug, mDuration, mIsFinite, mScenario, and mUpdateInterval.

Referenced by Create(), WsfOrbitalAttitudeChangeEvent::ProcessInput(), WsfOrbitalScriptEvent::ProcessInput(), and WsfOrbitalMissionSequence::ProcessInputWithIgnore().

◆ SetCanceled()

void WsfOrbitalEvent::SetCanceled ( )

inline

Mark the event as canceled.

References mIsCanceled.

◆ SetCondition()

void WsfOrbitalEvent::SetCondition ( std::unique_ptr< wsf::space::OrbitalPropagatorCondition > aConditionPtr )

inline

Set the condition for execution.

References mCondition.

◆ SetDuration()

void WsfOrbitalEvent::SetDuration ( const UtTimeValue & aDuration )

Set the full duration of the event. A value of 0 implies and impulsive event; otherwise it is finite.

References mDuration, and mIsFinite.

◆ SetFinite()

void WsfOrbitalEvent::SetFinite ( bool aIsFinite )

inline

Set whether the event is finite.

References mIsFinite.

◆ SetOnlyDuration()

void WsfOrbitalEvent::SetOnlyDuration ( const UtTimeValue & aDuration )

Set only the duration.

Unlike SetDuration, this method has not side effects on if the event is considered to be finite or not. Note that if the event is not set to be finite through some other means, this may result in no effect on the resulting simulation.

Parameters

aDuration - The duration to set on the event.

References mDuration.

◆ SetStartTime()

void WsfOrbitalEvent::SetStartTime ( const UtCalendar & aStartTime )

inline

Set the start time to begin event execution.

References mStartTime.

Referenced by UT_DEFINE_SCRIPT_METHOD(), UT_DEFINE_SCRIPT_METHOD(), and UT_DEFINE_SCRIPT_METHOD().

◆ SetUpdateInterval()

void WsfOrbitalEvent::SetUpdateInterval ( const UtTimeValue & aUpdateInterval )

inline

Set the update interval for which the event is to be re-evaluated.

References mUpdateInterval.

◆ ValidateParameterRanges()

bool WsfOrbitalEvent::ValidateParameterRanges ( const std::string & aExecutingPlatformName ) const

virtual

Check that the event's parameters are in the valid range for each parameter. When deriving from WsfOrbitalEvent, the subclass should call into this method to apply the checks on any parameters related to the event being finite.

Parameters

aExecutingPlatformName The name of the platform that would be executing this event.

Returns: True if the event parameters are all in allowed ranges.

Reimplemented in WsfOrbitalAttitudeChangeEvent.

References WsfObject::GetType(), mCondition, mDuration, mIsFinite, and mUpdateInterval.

Referenced by WsfOrbitalAttitudeChangeEvent::ValidateParameterRanges().

◆ VerifyCondition()

bool WsfOrbitalEvent::VerifyCondition ( ) const

virtual

Verify that the condition set in the event is one of the possible valid constraints. Note that when executed the constraint may not be valid at the time.

Reimplemented in WsfOrbitalManeuver.

References wsf::space::ApoapsisCondition::cTYPE, wsf::space::AscendingNodeCondition::cTYPE, wsf::space::DescendingNodeCondition::cTYPE, wsf::space::EclipseEntryCondition::cTYPE, wsf::space::EclipseExitCondition::cTYPE, wsf::space::NoneCondition::cTYPE, wsf::space::PeriapsisCondition::cTYPE, wsf::space::RelativeTimeCondition::cTYPE, and mCondition.

Referenced by Initialize().

Member Data Documentation

◆ mCanVerify

bool WsfOrbitalEvent::mCanVerify

protected

Referenced by CanVerify(), WsfOrbitalEvent(), WsfOrbitalEvent(), and WsfOrbitalScriptEvent::WsfOrbitalScriptEvent().

◆ mCondition

ut::CloneablePtr<wsf::space::OrbitalPropagatorCondition> WsfOrbitalEvent::mCondition {}

protected

Referenced by WsfOrbitalMissionSequence::ComputeContraintEpoch(), GetCondition(), GetCondition(), GetConditionString(), Initialize(), InitializeTimes(), WsfOrbitalManeuver::InitializeTimes(), ProcessInput(), SetCondition(), ValidateParameterRanges(), VerifyCondition(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mDebug

bool WsfOrbitalEvent::mDebug

protected

Referenced by WsfOrbitalMissionSequence::AdvanceMissionEvent(), ProcessInput(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mDuration

UtTimeValue WsfOrbitalEvent::mDuration

protected

Referenced by EvaluateCompletion(), GetDuration(), WsfOrbitalManeuver::InitializeTimes(), ProcessInput(), SetDuration(), SetOnlyDuration(), ValidateParameterRanges(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mEvaluationTime

UtCalendar WsfOrbitalEvent::mEvaluationTime

protected

Referenced by WsfOrbitalManeuver::ExecuteEvent(), GetEvaluationTime(), WsfOrbitalManeuver::GetRequiredDeltaV(), WsfOrbitalMissionSequence::Initialize(), InitializeTimes(), WsfOrbitalManeuver::InitializeTimes(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mHasExecuted

bool WsfOrbitalEvent::mHasExecuted

protected

Referenced by AdvanceMissionEvent(), Execute(), WsfOrbitalMissionSequence::GetCurrentMissionEvent(), WsfOrbitalMissionSequence::GetCurrentMissionEvent(), HasExecuted(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mIsCanceled

bool WsfOrbitalEvent::mIsCanceled

protected

Referenced by IsCanceled(), SetCanceled(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mIsComplete

bool WsfOrbitalEvent::mIsComplete

protected

Referenced by WsfOrbitalMissionSequence::AdvanceMissionEvent(), Execute(), IsComplete(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mIsFinite

bool WsfOrbitalEvent::mIsFinite

protected

Referenced by WsfOrbitalManeuver::InitializeTimes(), IsFinite(), ProcessInput(), SetDuration(), SetFinite(), ValidateParameterRanges(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mScenario

const WsfScenario& WsfOrbitalEvent::mScenario

protected

Referenced by ProcessInput(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mStartTime

UtCalendar WsfOrbitalEvent::mStartTime

protected

Can this event be verified without running in a simulation?

Referenced by EvaluateCompletion(), Execute(), GetStartTime(), WsfOrbitalMissionSequence::Initialize(), InitializeTimes(), WsfOrbitalManeuver::InitializeTimes(), SetStartTime(), WsfOrbitalEvent(), and WsfOrbitalEvent().

◆ mUpdateInterval

UtTimeValue WsfOrbitalEvent::mUpdateInterval

protected

Referenced by GetUpdateInterval(), ProcessInput(), SetUpdateInterval(), ValidateParameterRanges(), WsfOrbitalEvent(), and WsfOrbitalEvent().

The documentation for this class was generated from the following files:

Classes

Public Member Functions

Static Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ WsfOrbitalEvent() [1/2]

◆ ~WsfOrbitalEvent()

◆ WsfOrbitalEvent() [2/2]

Member Function Documentation

◆ Accept()

◆ AdvanceMissionEvent()

◆ CanVerify()

◆ Clone()

◆ Create() [1/2]

◆ Create() [2/2]

◆ EvaluateCompletion()

◆ EvaluatePostconditions()

◆ EvaluatePreconditions()

◆ Execute()

◆ ExecuteEvent()

◆ GetCondition() [1/2]

◆ GetCondition() [2/2]

◆ GetConditionString()

◆ GetCurrentMissionEvent() [1/2]

◆ GetCurrentMissionEvent() [2/2]

◆ GetDeltaV()

◆ GetDuration()

◆ GetEvaluationTime()

◆ GetNextExecutionTime()

◆ GetRequiredDeltaV()

◆ GetScriptClassName()

◆ GetStartTime()

◆ GetUpdateInterval()

◆ HasExecuted()

◆ Initialize()

◆ InitializeTimes()

◆ InitializeVariables()

◆ IsCanceled()

◆ IsComplete()

◆ IsFinite()

◆ IsSequence()

◆ operator=()

◆ ProcessInput()

◆ SetCanceled()

◆ SetCondition()

◆ SetDuration()

◆ SetFinite()

◆ SetOnlyDuration()

◆ SetStartTime()

◆ SetUpdateInterval()

◆ ValidateParameterRanges()

◆ VerifyCondition()

Member Data Documentation

◆ mCanVerify

◆ mCondition

◆ mDebug

◆ mDuration

◆ mEvaluationTime

◆ mHasExecuted

◆ mIsCanceled

◆ mIsComplete

◆ mIsFinite

◆ mScenario

◆ mStartTime

◆ mUpdateInterval
